Toyota CELICA — CAUTION PLATE & NAME PLATE (ENGINE)

11283PLATE, TURBOCHARGER CAUTION

main11294-42010i3SGTE..ST165..USA198710-198908

main11294-42020i3SGTE..ST165..CND198710-198908

11284PLATE, ENGINE BOLT INFORMATION

main11284-74020i3SGTE..ST165198710-198908

11286PLATE, ENGINE SPECIFICATION

main11286-88380i3SGTE..ST165198710-198908

11288PLATE, ENGINE SYSTEM

main11288-74020i3SFE..ST162198708-198907

main11288-88360i3SGELC..ST162198708-198908

main11288-88380i3SGTE..ST165198710-198908

11289PLATE, SPARK PLUG CAUTION

main11289-73020i3SG#..ST16#198708-198908

11291PLATE, ENGINE NAME

main11291-88360i3SGELC..ST162198708-198908

main11291-88380i3SGTE..ST165198710-198908

11292PLATE, ENGINE NAME, NO.2

main11292-74020i3SFE..ST162198708-198808

main11292-74021i3SFE..ST162198808-198907

11298PLATE, EMISSION CONTROL INFORMATION

main11298-74251i3SGELC..ST162198708-198808

main11298-74252i3SGELC..ST162198808-198908

main11298-74261i3SGELC..ST162..USA198708-198808

CALIFORNIA SPEC

main11298-74262i3SGELC..ST162..USA198808-198908

CALIFORNIA SPEC

main11298-74280i3SGTE..ST165198710-198808

main11298-74281i3SGTE..ST165198808-198908

main11298-74290i3SGTE..ST165..USA198710-198808

CALIFORNIA SPEC

main11298-74291i3SGTE..ST165..USA198808-198908

CALIFORNIA SPEC

main11298-74320i3SFE..ST162198708-198808

main11298-74321i3SFE..ST162198808-198908

main11298-74330i3SFE..ST162..USA198708-198808

CALIFORNIA SPEC

main11298-74331i3SFE..ST162..USA198808-198908

CALIFORNIA SPEC

17700CPLATE, AIR CLEANER CAUTION (FOR ENGINE MODEL)

main17791-35010i3SGTE..ST165198710-198908

17700DPLATE, ENGINE CAUTION

main11293-74070i3SFE,3SGELC..ST162198708-198908

17792PLATE, ENGINE VACUUM HOSE INFORMATION

main17792-74061i3SGELC..ST162..5F198708-198908

main17792-74091i3SGELC..ST162..4FC198708-198908

main17792-74120i3SFE..ST162..5F198708-198908

main17792-74130i3SFE..ST162..4FC198708-198908

main17792-74160i3SGTE..ST165198710-198908

sub17792-74161

11 parts on this diagram · 1 diagram in section
