Toyota CAMRY — DISC WHEEL & WHEEL CAP

0001 1 0002 1

42603ORNAMENT SUB-ASSY, WHEEL HUB

main42603-32010iCV10,SV11198301-198408

TYPE A

main42603-32020iSV11..LE198301-198408

ALUMI WHEEL,TYPE B

main42603-32030iCV1#,SV11198408-198607

TYPE C

main42638-32040iSV11..LE198408-198607

ALUMI WHEEL,TYPE D

42611ATIRE TUBE SET OR TUBELESS TIRE

main42652-12280iCV1#,SV11198301-198607

185/70SR13

main42652-12400iSV11..5F..DLX198301-198508

165SR13

main42652-32050iCV1#,SV11198301-198607

T125/70D14,SPAR

42611GVALVE (FOR TUBELESS TIRE)

main90942-05009iCV1#,SV11198301-198607

42621CAP, WHEEL

main42621-32010iSV11..CND198408-198607

42624RING, WHEEL CAP

main42624-32020iCV10,SV11198308-198607

5 parts on this diagram · 2 diagrams in section
