Toyota BZ4X (GTMC) — REAR COMBINATION LAMP

6101SIDE MEMBER

→ Go to FIG 61-01

81496GUIDE, REAR COMBINATION LAMP

main81496-0D030×2i202411

(L)

main81496-52020×2i202211-202411

(J)

81496CGUIDE, REAR COMBINATION LAMP, NO.2

main81496-60010×2i202211-202411

TYPE A

main90467-C0019×2i202411

TYPE B

81497COVER, REAR COMBINATION LAMP, RH

main81497-0R040i202411

81498COVER, REAR COMBINATION LAMP, LH

main81498-0R040i202211-202411

81536BLED, REAR TURN SIGNAL LAMP

main81965-42010×2i202312-202411

81550LAMP ASSY, REAR COMBINATION, RH

main81550-0R120i202211-202311

main81550-0R121i202411

81560LAMP ASSY, REAR COMBINATION, LH

main81560-0R120i202211-202311

main81560-0R121i202411

81580ALAMP ASSY, REAR

main81580-0R090i202411

9015960621

main90159-60621

90178C0057

main90178-C0057

9018906235

main90189-06235

9018906242

main90189-06242

13 parts on this diagram · 1 diagram in section

REAR COMBINATION LAMP for Toyota BZ4X (GTMC)

This section contains 13 genuine Toyota parts for the REAR COMBINATION LAMP system of the Toyota BZ4X (GTMC). Key components include: SIDE MEMBER, GUIDE, REAR COMBINATION LAMP, GUIDE, REAR COMBINATION LAMP, NO.2, COVER, REAR COMBINATION LAMP, RH, COVER, REAR COMBINATION LAMP, LH.
