Toyota AVENSIS — REAR SPRING & SHOCK ABSORBER

42304CARRIER SUB-ASSY, REAR AXLE, RH

main42304-05100iADT251,AZT25#,CDT250,ZZT25#200309-200604

main42304-05101iADT25#,AZT25#,ZZT25#200604

main42304-05130iAZT250,CDT250,ZZT25#200301-200309

sub42304-05100

42305CARRIER SUB-ASSY, REAR AXLE, LH

main42305-05100iADT251,AZT25#,CDT250,ZZT25#200309-200604

main42305-05101iADT25#,AZT25#,ZZT25#200604

main42305-05130iAZT250,CDT250,ZZT25#200301-200308

sub42305-05100

48060BRACKET ASSY, REAR SUSPENSION ARM, RH

main48060-05010iAZT250,CDT250,ZZT25#200301-200308

sub48060-05011

main48060-05011iADT251,AZT25#,CDT250,ZZT25#200308-200604

main48060-05012iADT25#,AZT25#,ZZT25#200604

48070BRACKET ASSY, REAR SUSPENSION ARM, LH

main48070-05010iAZT250,CDT250,ZZT25#200301-200308

sub48070-05011

main48070-05011iADT251,AZT25#,CDT250,ZZT25#200308-200604

main48070-05012iADT25#,AZT25#,ZZT25#200604

48190RCAM ASSY, CAMBER ADJUST

main48190-32010iADT251,AZT25#,CDT250,ZZT25#200301-200604

48198HCAM, CAMBER ADJUST, NO.2

main48198-32040iADT251,AZT25#,CDT250,ZZT25#200301-200604

48231ASPRING, COIL, REAR RH

main48231-05300iADT251,AZT25#,CDT250,ZZT25#..SED..(ELEGT,TEC)200301-200604

main48231-05310iAZT25#,CDT250,ZZT25#..WG200301-200310

sub48231-05311

main48231-05311iADT251,AZT25#,CDT250,ZZT25#..WG200310-200604

main48231-05320iADT251,CDT250,ZZT25#..SED..ENTRY200301-200604

main48231-05440iADT251,AZT25#,CDT250,ZZT25#..LB200310-200604

48231BSPRING, COIL, REAR LH

main48231-05300iADT25#,AZT25#,ZZT25#..SED200301-200604

main48231-05310iAZT25#,CDT250,ZZT25#..WG200301-200310

sub48231-05311

main48231-05311iADT251,AZT25#,CDT250,ZZT25#..WG200310-200604

main48231-05320iADT251,CDT250,ZZT25#..SED..ENTRY200301-200604

main48231-05440iADT251,AZT25#,CDT250,ZZT25#..LB200310-200604

48257CINSULATOR, REAR COIL SPRING, UPPER RH

main48257-05010iADT251,AZT25#,CDT250,ZZT25#200301-200604

48259AINSULATOR, REAR COIL SPRING, UPPER LH

main48257-05010iADT251,AZT25#,CDT250,ZZT25#200301-200604

48341ABUMPER, REAR SPRING, NO.1 RH

main48341-05030iADT251,AZT25#,CDT250,ZZT25#200301-200604

48341BBUMPER, REAR SPRING, NO.1 LH

main48341-05030iADT251,AZT25#,CDT250,ZZT25#200301-200604

48401BRACKET SUB-ASSY, REAR SPRING, FRONT RH

main48401-32010iADT251,AZT25#,CDT250,ZZT25#200301-200604

48402BRACKET SUB-ASSY, REAR SPRING, FRONT LH

main48401-32010iADT251,AZT25#,CDT250,ZZT25#200301-200604

48530ABSORBER ASSY, SHOCK, REAR RH

main48530-09650iCDT250,ZZT25#..SED..ENTRY200301-200306

MARK 48530-05230

main48530-09651iZZT251..SED..5F..ENTRY;ZZT251..SED..(ELEGT,TEC);AZT25#,CDT250,ZZT250..SED;ZZT251..LHD..SED..4FC..ENTRY200306-200408

MARK 48530-05231

sub48530-09E60

main48530-09660iCDT250,ZZT25#..LB..ENTRY;AZT250,CDT250,ZZT25#..(LB,SED)..(ELEGT,TEC)200301-200306

MARK 48530-05240

main48530-09661iAZT250..SED..4FC..D4200306-200408

MARK 48530-05241

sub48530-09E80

main48530-09670iAZT250,CDT250,ZZT25#..WG200301-200306

MARK 48530-05250

main48530-09A01iAZT25#,CDT250,ZZT25#..WG200306-200408

MARK 48530-05251

sub48530-09E90

main48530-09E60iZZT251..SED..5F..ENTRY;ZZT251..SED..(ELEGT,TEC);ZZT251..LHD..SED..4FC..ENTRY;ADT251,AZT25#,CDT250,ZZT250..SED200408-200604

MARK 48530-05231

main48530-09E80iADT251,AZT25#,CDT250,ZZT25#..LB200408-200604

MARK 48530-05241

main48530-09E90iADT251,AZT25#,CDT250,ZZT25#..WG200408-200604

MARK 48530-05251

main48530-09L20iADT25#,AZT25#,ZZT25#200604

MARK 48530-05232

48530BWASHER, REAR SHOCK ABSORBER CUSHION, NO.1

main90948-03021iADT251,AZT25#,CDT250,ZZT25#200301-200604

48530GCUSHION, REAR SHOCK ABSORBER, NO.1

main48755-05010iADT25#,AZT25#,ZZT25#200301-200604

48540ABSORBER ASSY, SHOCK, REAR LH

main48530-09650iCDT250,ZZT25#..SED..ENTRY200301-200306

MARK 48530-05230

main48530-09651iZZT251..RHD..SED..4FC..ENTRY200306-200408

MARK 48530-05231

sub48530-09E60

main48530-09660iCDT250,ZZT25#..LB..ENTRY;AZT250,CDT250,ZZT25#..(LB,SED)..(ELEGT,TEC)200301-200306

MARK 48530-05240

main48530-09661iAZT250..SED..4FC..D4200306-200408

MARK 48530-05241

sub48530-09E80

main48530-09670iAZT250,CDT250,ZZT25#..WG200301-200306

MARK 48530-05250

main48530-09A01iAZT25#,CDT250,ZZT25#..WG200306-200408

MARK 48530-05251

sub48530-09E90

main48530-09E60iZZT251..SED..5F..ENTRY;ZZT251..SED..(ELEGT,TEC);ZZT251..LHD..SED..4FC..ENTRY;ADT251,AZT25#,CDT250,ZZT250..SED200408-200604

MARK 48530-05231

main48530-09E80iADT251,AZT25#,CDT250,ZZT25#..LB200408-200604

MARK 48530-05241

main48530-09E90iADT251,AZT25#,CDT250,ZZT25#..WG200408-200604

MARK 48530-05251

main48530-09L20iADT25#,AZT25#,ZZT25#200604

MARK 48530-05232

48702CBUSH SUB-ASSY, LOWER CONTROL ARM

main48704-05010iADT251,AZT25#,CDT250,ZZT25#200301-200604

RH

main48704-05030iADT25#,AZT25#,ZZT25#200301-200604

LH

48710AARM ASSY, REAR SUSPENSION, NO.1 RH

main48710-05070iADT251,AZT25#,CDT250,ZZT25#200301-200604

sub48710-21030

main48710-05071iADT25#,AZT25#,ZZT25#200604

sub48710-21030

48720ARM ASSY, LOWER CONTROL, RH

main48720-05020iADT251,AZT25#,CDT250,ZZT25#200301-200604

sub48720-21020

48720AARM ASSY, REAR SUSPENSION, NO.1 LH

main48720-05010iADT251,AZT25#,CDT250,ZZT25#200301-200604

sub48720-21010

main48720-05011iADT25#,AZT25#,ZZT25#200604

sub48720-21010

48725BUSH, LOWER CONTROL ARM

main48725-05080iADT25#,AZT25#,ZZT25#200301-200604

48725BBUSH, REAR SUSPENSION ARM, NO.1

main48725-05070iADT251,AZT25#,CDT250,ZZT25#200301-200604

main48725-05071iADT25#,AZT25#,ZZT25#200604

48725FBUSH, REAR AXLE CARRIER, RH

main48725-05090iADT251,AZT25#,CDT250,ZZT25#200301-200604

NO.1

main48725-05091iADT25#,AZT25#,ZZT25#200604

NO.1

main48725-05140iADT251,AZT25#,CDT250,ZZT25#200301-200604

NO.2

main48725-05141iADT25#,AZT25#,ZZT25#200604

NO.2

48725GBUSH, REAR AXLE CARRIER, LH

main48725-05090iADT251,AZT25#,CDT250,ZZT25#200301-200604

NO.1

main48725-05091iADT25#,AZT25#,ZZT25#200604

NO.1

main48725-05140iADT251,AZT25#,CDT250,ZZT25#200301-200604

NO.2

main48725-05141iADT25#,AZT25#,ZZT25#200604

NO.2

48730ARM ASSY, LOWER CONTROL, LH

main48730-05060iADT251,AZT25#,CDT250,ZZT25#200301-200604

sub48730-21110

48750HSUPPORT ASSY, REAR SUSPENSION, RH

main48750-05040iADT251,AZT25#,CDT250,ZZT25#200301-200604

48752ASTOPPER, REAR SUSPENSION SUPPORT

main48752-05010iADT251,AZT25#,CDT250,ZZT25#200301-200604

48760BSUPPORT ASSY REAR SUSPENSION, LH

main48750-05040iADT251,AZT25#,CDT250,ZZT25#200301-200604

48770AARM ASSY, UPPER CONTROL, REAR RH

main48770-05010iAZT25#,CDT250,ZZT25#200301-200402

sub48770-21011

main48770-21011iADT251,AZT25#,CDT250,ZZT25#200403-200604

48790ARM ASSY, UPPER CONTROL, REAR LH

main48770-05010iAZT25#,CDT250,ZZT25#200301-200402

sub48770-21011

main48770-21011iADT25#,AZT25#,ZZT25#200403-200604

48812BAR, STABILIZER, REAR

main48812-05070iADT251,AZT25#,CDT250,ZZT25#..WG200301-200604

main48812-05080iADT251,AZT25#,CDT250,ZZT25#..LB,SED200301-200604

48818BUSH, STABILIZER, REAR

main48818-05070iADT25#,AZT25#,ZZT25#200301-200604

main48818-05080iADT251,AZT25#,CDT250,ZZT25#..LB,SED200301-200604

48830DLINK ASSY, REAR STABILIZER, RH

main48830-21020iADT251,AZT25#,CDT250,ZZT25#200301-200604

48832CBRACKET, REAR STABILIZER BAR, NO.3

main48832-05010iADT251,AZT25#,CDT250,ZZT25#200301-200604

48840ALINK ASSY, REAR STABILIZER, LH

main48840-21010iADT251,AZT25#,CDT250,ZZT25#200301-200604

8401

9010512323

main90105-12323

9011912154

main90119-12154

9011912285

main90119-12285

9011912330

main90119-12330

9011914025

main90119-14025

9011914086

main90119-14086

90119W0004

main90119-W0004

90119W0057

main90119-W0057

90119W0079

main90119-W0079

90119W0085

main90119-W0085

90119W0086

main90119-W0086

9017114012

main90171-14012

9017810014

main90178-10014

9017812007

main90178-12007

9017812010

main90178-12010

9017814005

main90178-14005

90178W0003

main90178-W0003

90178W0035

main90178-W0035

90178W0047

main90178-W0047

9017910183

main90179-10183

9017912078

main90179-12078

9017912127

main90179-12127

9017914045

main90179-14045

9017918016

main90179-18016

9017918017

main90179-18017

9046816038

main90468-16038

91672J1020

main91672-J1020

9415181041

main94151-81041

66 parts on this diagram · 1 diagram in section
