Toyota 4RUNNER — SWITCH & RELAY & COMPUTER

0001 1ENGINE & TRANSMISSION 0002 1ENGINE ROOM 0003 1ENGINE ROOM 0004 1ENGINE ROOM RELAY BLOCK 0005 1ENGINE ROOM RELAY BLOCK 0006 1COWL 0007 1COWL 0008 1COWL 0009 1INSTRUMENT PANEL 0010 1INSTRUMENT PANEL(1/2) 0011 1INSTRUMENT PANEL(2/2) 0012 1INSTRUMENT PANEL(2/2) 0013 1STEERING 0014 1STEERING 0015 1SEAT 0016 1DOOR,ROOF,FLOOR & BACK DOOR

83530SWITCH ASSY, OIL PRESSURE (FOR ENGINE)

main83530-60020iGRN28#200908-201308

84540SWITCH ASSY, NEUTRAL START

main84540-35060iGRN28#201908-202007

main84540-35061iGRN28#202008

main84540-60050iGRN28#201308-201610

89465SENSOR, OXYGEN

main89465-35780supersedes 89465-60430iGRN28#201908

CHILE SPEC

89465ASENSOR, OXYGEN NO.2

main89465-35770supersedes 89465-60320iGRN28#201406-201908

CHILE SPEC

89467BSENSOR, AIR FUEL RATIO

main89467-52110supersedes 89467-60060iGRN28#201908

CHILE SPEC,LH

main89467-60100supersedes 89467-60060iGRN28#201908

CHILE SPEC,RH

89491SENSOR, ENGINE OIL LEVEL

main89491-60140iGRN28#201509-201608

CHILE SPEC

89615SENSOR, KNOCK CONTROL

main89615-20090×2iGRN28#201908

8271535840BRACKET,WIRING HARNESS CLAMP

main82715-35840

8271560P10BRACKET,WIRING HARNESS CLAMP

main82715-60P10

9011908C62

main90119-08C62

90119A0406

main90119-A0406

9155180830

main91551-80830

9167180612

main91671-80612

9167180616

main91671-80616

14 parts on this diagram · 16 diagrams in section
