RADIO RECEIVER & AMPLIFIER & CONDENSER

0001 1 0002 1 0003 1 0004 1 0005 1 0006 1 0007 1

86120RECEIVER ASSY, RADIO

main86120-02130iRCK10,VCK11,21..RCB; VCK11,21..XTR..DLX199508-199708

MATSUSHITA, ID=51203; MATSUSHITA, ID=51203,AM/FM MPX 2SP 10KHZ

main86120-02140iVCK11..XTR..USA;VCK21..XTR..SR5;VCK21..XTR..DLX..USA199410-199708

MATSUSHITA, ID=51403,AM/FM MPX

main86120-02150iVCK11,21..SR5199708-199807

MATSUSHITA, ID=51801

main86120-04080iRCK10,VCK11,21199708-199807

MATSUSHITA,ID=A56200,*35 9KHZ

main86120-04090iVCK11,21..XTR199708-199807

MATSUSHITA,ID=A56409,AM/FM MPX 2SP

main86120-0W020iVCK11,21..RCB..SR5199408-199508

MATSUSHITA, ID=51404

main86120-0W040iRCK10,VCK11,21..RCB199408-199508

MATSUSHITA, ID=56406,*35 10KHZ 4AMP

main86120-0W060iVCK11,21..XTR199708-199807

MATSUSHITA, ID=51707,AM/FM MULTIPLEX ETR CASSETTE CD 4SPEAKER

main86120-12860iRCK10,VCK10,20..STD199308-199408

MATSUSHITA,AM/FM MPX 2SP 10KHZ

main86120-17310iVCK1#,2#..SR5..USA199208-199508

MATSUSHITA,ID=57404,*35 9KHZ

main86120-17320iRCK10,VCK10,20199208-199408

MATSUSHITA,*35 10KHZ 4AMP

main86120-17330iVCK10,20..SR5199208-199408

MATSUSHITA,*36 10KHZ

main86120-17340iVCK10,20..SR5199208-199408

MATSUSHITA, ID=56805,*36 & CD

main86120-17350iVCK11,21..RCB..SR5199408-199508

MATSUSHITA, ID=51705,*36 10KHZ

main86120-33030iVCK11,21..XTR..SR5199410-199708

MATSUSHITA,ID=51706,*36 6SP

main86120-34010iVCK10,20..SR5199208-199408

MATSUSHITA,AM/FM MPX 4SP

main86120-35040iVCK10,20..STD..USA199208-199308

MATSUSHITA,AM/FM MPX 2SP 9KHZ

main86120-35160iVCK11,21..SR5199708-199807

MATSUSHITA, ID=51800,AM/FM ETR CASSETTE (AM=10KHZ STEP)

main86120-AC010iVCK11,21..XTR199410-199708

MATSUSHITA, ID=56405,*36 4SP

86211BRACKET, RADIO, NO.1

main86211-89111iRCK10,VCK1#,2#199208

86212BRACKET, RADIO, NO.2

main86212-89111iRCK10,VCK1#,2#199208

9014950032

main90149-50032

9015350010

main90153-50010

5 parts on this diagram · 7 diagrams in section
