CENTER SUPPORT & PLANETARY SUN GEAR (ATM)

35608SPRING SUB-ASSY, 2ND BRAKE PISTON RETURN

main35608-30010iRCK10,VCK1#,2#..ATM199208

35624PISTON, 2ND BRAKE

main35624-30010iRCK10,VCK1#,2#..ATM199208

35624ARING, O (FOR 2ND BRAKE PISTON)

main90301-85001iRCK10,VCK1#,2#..ATM199208

INNER

main90301-99038iRCK10,VCK1#,2#..ATM199208

OUTER

35626CSLEEVE, 2ND BRAKE PISTON

main35626-30030iRCK10,VCK1#,2#..ATM199208

35627BSEAT, 2ND BRAKE PISTON RETURN SPRING

main35627-30010iRCK10,VCK1#,2#..ATM199208

35627CRING, SHAFT SNAP(FOR 2ND BRAKE PISTON RETURN SPRING SEAT)

main90520-54001iRCK10,VCK1#,2#..ATM199208

35648PLATE, CLUTCH (FOR 2ND BRAKE)

main35647-30020×4iRCK10,VCK1#,2#..ATM199208

T=2.5

main35647-30030iRCK10,VCK1#,2#..ATM199208

T=1.8

35676FLANGE, BRAKE (FOR 2ND BRAKE)

main35676-30020iRCK10,VCK1#,2#..ATM199208

T=3.0

35676ERING, HOLE SNAP (FOR 2ND BRAKE)

main90521-99032iRCK10,VCK1#,2#..ATM199208

35677DISC, CLUTCH (FOR 2ND BRAKE)

main35667-30020×5iRCK10,VCK1#,2#..ATM199208-199708

main35667-60010×5iRCK10,VCK11,21..ATM199708

35706HGEAR SUB-ASSY, PLANETARY SUN

main35706-30061iRCK10,VCK1#,2#..ATM199208

35706JBEARING, THRUST NEEDLE ROLLER (FOR PLANETARY SUN GEAR)

main90374-30006iRCK10,VCK1#,2#..ATM199208

35709FDRUM SUB-ASSY, 2ND BRAKE

main35709-30061iRCK10,VCK1#,2#..ATM199304

main35709-50010iVCK10,20..ATM199208-199304

35709GRING, HOLE SNAP (FOR 2ND BRAKE DRUM)

main90521-99044iRCK10,VCK1#,2#..ATM199208

35729AWASHER, PLANETARY CARRIER THRUST, NO.4

main35729-30010iRCK10,VCK1#,2#..ATM199208

35738AWASHER, 1 WAY CLUTCH THRUST, NO.1

main35738-30040iRCK10,VCK1#,2#..ATM199208

35749ARING, SUN GEAR SHAFT OIL SEAL

main35749-30010×2iRCK10,VCK1#,2#..ATM199208

35755DRUM, SUN GEAR INPUT

main35755-50010iRCK10,VCK1#,2#..ATM199208

35755ARING, SHAFT SNAP (FOR SUN GEAR INPUT DRUM)

main90520-46002iRCK10,VCK1#,2#..ATM199208

ID=46.0,T=1.2,RR

main90520-49001iRCK10,VCK1#,2#..ATM199208

ID=49.0,WD=2.3,FR

35789ERACE, THRUST BEARING (FOR PLANETARY SUN GEAR)

main35789-30150iRCK10,VCK1#,2#..ATM199208

35790CLUTCH ASSY, 1 WAY

main35790-30060iRCK10,VCK1#,2#..ATM199405

main35790-50010iVCK10,20..ATM199208-199405

21 parts on this diagram · 1 diagram in section
