DISC WHEEL & WHEEL CAP

0001 1 0002 1 0003 1

42601AWHEEL, DISC (FOR SPARE)

main42611-60130iFZJ80199511-199801

16X8JJ

42601CNUT, HUB (FOR AXLE)

main90942-01077×24iFZJ80199511-199801

42601FWHEEL, DISC (FOR FRONT)

main42611-60130×2iFZJ80199511-199801

16X8JJ

42601RWHEEL, DISC (FOR REAR)

main42611-60130×2iFZJ80199511-199801

16X8JJ

42611GVALVE (FOR TUBELESS TIRE)

main90942-05009×4iFZJ80199511-199801

42611JVALVE (FOR TUBELESS TIRE SPARE)

main90942-05009iFZJ80199511-199801

42652TIRE

main42652-0W180×4iFZJ80199608-199801

P275/70R16

main42652-60182×4iFZJ80199511-199608

P275/70R16

main42652-60191×4iFZJ80199511-199601

275/70R16,*B/S

main42652-60192×4iFZJ80199601-199608

275/70R16,*B/S

main42652-60193×4iFZJ80199608-199801

275/70R16,*B/S

42652ATIRE (FOR SPARE)

main42652-0W180iFZJ80199608-199801

P275/70R16

main42652-60182iFZJ80199511-199608

P275/70R16

main42652-60191iFZJ80199511-199601

275/70R16,*B/S

main42652-60192iFZJ80199601-199608

275/70R16,*B/S

main42652-60193iFZJ80199608-199801

275/70R16,*B/S

8 parts on this diagram · 3 diagrams in section
