SWITCH & RELAY & COMPUTER

0001 1ENGINE & TRANSMISSION 0002 1ENGINE ROOM 0003 1ENGINE ROOM 0004 1ENGINE ROOM 0005 1ENGINE ROOM RELAY BLOCK 0006 1ENGINE ROOM RELAY BLOCK 0007 1ENGINE ROOM RELAY BLOCK 0008 1COWL 0009 1COWL 0010 1COWL 0011 1INSTRUMENT PANEL 0012 1INSTRUMENT PANEL 0013 1INSTRUMENT PANEL 0014 1INSTRUMENT PANEL 1/2 0015 1INSTRUMENT PANEL 2/2 0016 1STEERING 0017 1STEERING 0018 1SEAT 0019 1DOOR & ROOF 0020 1FLOOR & BACK DOOR

83530SWITCH ASSY, OIL PRESSURE (FOR ENGINE)

main83530-28020iURJ150201308-201908

DENSO

main83530-60020iURJ150201308-201908

YAZAKI

84540SWITCH ASSY, NEUTRAL START

main84540-35060iURJ150201611-201908

main84540-35061iURJ150202008

main84540-60050iURJ150201308-201610

89421BSENSOR, VACUUM

main89421-47010iURJ150201908

main89421-52010iURJ150200911-201009

89465SENSOR, OXYGEN

main89465-35720iURJ150200911-201308

main89465-60460iURJ150201908-202108

main89465-60600iURJ150202108

89465ASENSOR, OXYGEN NO.2

main89465-34160iURJ150201908-202108

main89465-36040iURJ150200911-201308

main89465-60520iURJ150202108

89467BSENSOR, AIR FUEL RATIO

main89467-35110×2iURJ150200911-201308

main89467-60140×2iURJ150201908-202111

89491SENSOR, ENGINE OIL LEVEL

main89491-60170iURJ150201908

89491AGASKET, ENGINE OIL LEVEL SENSOR

main89493-60010iURJ150201308-201908

89615SENSOR, KNOCK CONTROL

main89615-20090×4iURJ150200911-201308

8271535D00BRACKET,WIRING HARNESS CLAMP

main82715-35D00

8271535D10BRACKET,WIRING HARNESS CLAMP

main82715-35D10

8271535D20BRACKET,WIRING HARNESS CLAMP

main82715-35D20

9011908C62

main90119-08C62

9016360025

main90163-60025

91511B0830

main91511-B0830

91621B0616

main91621-B0616

9167180612

main91671-80612

9167180816

main91671-80816

18 parts on this diagram · 20 diagrams in section
