FRONT DRUM BRAKE WHEEL CYLINDER & BACKING PLATE

0001 1 0002 1

04494SHOE KIT, FRONT BRAKE

main04494-35060iLJ72,RJ70..STD199001-199201

main04494-60030iFJ7#,HZJ75,PZJ7#..STD..GEN199001-199201

04905CUP KIT, FRONT WHEEL CYLINDER

main04905-35050iLJ72,RJ70..STD199001-199201

main04905-36070iFJ75,HZJ75,PZJ75..GEN199001-199201

main04905-60030iFJ70,73,PZJ70,73..STD..GEN199001-199201

47041PLATE SUB-ASSY, BRAKE BACKING, FRONT RH

main47041-60050iFJ7#,HZJ75,PZJ7#..STD..GEN199001-199201

main47041-60070iLJ72,RJ70..STD199001-199201

47041DBOLT(FOR BACKING PLATE TO STEERING KNUCKLE SETTING)

main90101-10166iFJ7#,HZJ75,LJ72,PZJ7#,RJ70..STD..GEN199006-199201

main90101-10439iFJ7#,HZJ75,LJ72,PZJ7#,RJ70..STD..GEN199001-199006

47042PLATE SUB-ASSY, BRAKE BACKING, FRONT LH

main47042-60010iFJ7#,HZJ75,PZJ7#..STD..GEN199001-199201

main47042-60030iLJ72,RJ70..STD199001-199201

47410CSPRING(FOR FRONT BRAKE SHOE HOLD DOWN)

main90501-20756iLJ72,RJ70..STD199001-199201

main90501-23002iFJ7#,HZJ75,PZJ7#..STD..GEN199001-199201

47410DSPRING, TENSION(FOR FRONT BRAKE SHOE RETURN)

main90506-23011iLJ72,RJ70..STD199001-199201

main90506-29006iFJ7#,HZJ75,PZJ7#..STD..GEN199001-199201

47410ESPRING, TENSION(FOR FRONT BRAKE SHOE RETURN)

main90506-23011iLJ72,RJ70..STD199001-199201

main90506-29006iFJ7#,HZJ75,PZJ7#..STD..GEN199001-199201

47419PLUG, HOLE(FOR FRONT BRAKE)

main47419-35011iFJ7#,HZJ75,PZJ7#..STD..GEN199001-199201

47447PIN, SHOE HOLD DOWN SPRING(FOR FRONT BRAKE)

main47447-20030iLJ72,RJ70..STD199001-199201

main47447-60010iFJ7#,HZJ75,PZJ7#..STD..GEN199001-199201

47449CUP, SHOE HOLD DOWN SPRING(FOR FRONT BRAKE)

main47449-30020iFJ7#,HZJ75,LJ72,PZJ7#,RJ70..STD..GEN199001-199201

47491PLUG, HOLE(FOR FRONT BRAKE)

main47491-36010iFJ7#,HZJ75,LJ72,PZJ7#,RJ70..STD..GEN199001-199201

47510CYLINDER ASSY, FRONT WHEEL BRAKE, RH(FOR FRONT OR UPPER)

main47520-35030iLJ72,RJ70..STD199001-199201

main47520-36090iFJ75,HZJ75,PZJ75..GEN199001-199201

main47520-60030iFJ70,73,PZJ70,73..STD..GEN199001-199201

47510CSPRING, COMPRESSION(FOR FRONT WHEEL BRAKE CYLINDER)

main90501-08122iFJ75,HZJ75,PZJ75..GEN199001-199201

main90501-10759iFJ70,73,PZJ70,73..STD..GEN199001-199201

47520CYLINDER ASSY, FRONT WHEEL BRAKE, RH(FOR REAR OR LOWER)

main47510-35060iLJ72,RJ70..STD199001-199201

main47510-36090iFJ75,HZJ75,PZJ75..GEN199001-199201

main47510-60100iFJ70,73,PZJ70,73..STD..GEN199001-199201

47530CYLINDER ASSY, FRONT WHEEL BRAKE, LH(FOR FRONT OR UPPER)

main47540-35030iLJ72,RJ70..STD199001-199201

main47540-36090iFJ75,HZJ75,PZJ75..GEN199001-199201

main47540-60030iFJ70,73,PZJ70,73..STD..GEN199001-199201

47533SEAT, WHEEL CYLINDER PISTON SPRING(FOR FRONT BRAKE)

main47533-25010iFJ70,73,PZJ70,73..STD..GEN199001-199201

main47533-30011iFJ75,HZJ75,PZJ75..GEN199001-199201

47540CYLINDER ASSY, FRONT WHEEL BRAKE, LH(FOR REAR OR LOWER)

main47530-35060iLJ72,RJ70..STD199001-199201

main47530-36090iFJ75,HZJ75,PZJ75..GEN199001-199201

main47530-60090iFJ70,73,PZJ70,73..STD..GEN199001-199201

47547PLUG, BLEEDER(FOR FRONT DRUM BRAKE)

main47547-12010iFJ7#,HZJ75,LJ72,PZJ7#,RJ70..STD..GEN199001-199201

47548CAP, BLEEDER PLUG(FOR DRUM BRAKE, FRONT)

main31478-30010iFJ7#,HZJ75,LJ72,PZJ7#,RJ70..STD..GEN199001-199201

47551NUT, FRONT WHEEL CYLINDER ADJUSTING, RH(FOR FRONT BRAKE)

main47551-26020iLJ72,RJ70..STD199001-199201

main47551-36120iFJ75,HZJ75,PZJ75..GEN199001-199201

main47551-60040iFJ70,73,PZJ70,73..STD..GEN199001-199201

47552NUT, FRONT WHEEL CYLINDER ADJUSTING, LH(FOR FRONT BRAKE)

main47552-26020iLJ72,RJ70..STD199001-199201

main47552-36120iFJ75,HZJ75,PZJ75..GEN199001-199201

main47552-60040iFJ70,73,PZJ70,73..STD..GEN199001-199201

47553BOLT, FRONT WHEEL CYLINDER ADJUSTING, RH(FOR FRONT BRAKE)

main47553-30051iLJ72,RJ70..STD199001-199201

main47553-36050iFJ7#,HZJ75,PZJ7#..STD..GEN199001-199201

47554BOLT, FRONT WHEEL CYLINDER ADJUSTING, LH(FOR FRONT BRAKE)

main47554-30051iLJ72,RJ70..STD199001-199201

main47554-36050iFJ7#,HZJ75,PZJ7#..STD..GEN199001-199201

47555SPRING, ADJUSTER LOCK(FOR FRONT BRAKE)

main47555-26030iLJ72,RJ70..STD199001-199201

main47555-36040iFJ7#,HZJ75,PZJ7#..STD..GEN199001-199201

47651LINING, FRONT BRAKE SHOE(FOR FRONT OR UPPER)

main47651-35060iLJ72,RJ70..STD199001-199201

main47651-60020iFJ7#,HZJ75,PZJ7#..STD..GEN199001-199201

47652LINING, FRONT BRAKE SHOE(FOR REAR OR LOWER)

main47651-35060iLJ72,RJ70..STD199001-199201

main47651-60020iFJ7#,HZJ75,PZJ7#..STD..GEN199001-199201

9010108043

main90101-08043

9015950146

main90159-50146

9451200800

main94512-00800

9451201000

main94512-01000

31 parts on this diagram · 2 diagrams in section
