DISC WHEEL & WHEEL CAP
42601WHEEL, DISC
15X6JJ,TYPE A:REFER ILLUST.
15X6JJ,TYPE A:REFER ILLUST.
15X6JJ,TYPE A:REFER ILLUST.
main42611-26170×4iKDH202..TH; KDH212,TRH213..VN; TRH201..ARL,SA;KDH221,TRH201..5D;TRH213..RHD..(10S,16S);TRH223..GL..(CIS,GCC,SA);TRH213..LHD..STD..(GCC,GEN);TRH223..STD..(ARL,GCC,GEN,TH);KDH212,TRH201..SG..(03S,10S,11S,16S)..5F..(GCC,GEN,SA);KDH200,222,TRH203..(03S,14S,15S,16S)..5F..(GCC,GEN,SA,TH);KDH201,202,203,220,223,LH20#,212,222,TRH221..(03S,06S,12S,14S,15S,16S)..(ARL,GCC,GEN,SA)200709-201008
15X6J,TIRE & DISK WHEEL-195R15C 8PR(ALUMINUM),TYPE B:REFER ILLUST.; 15X6J,WITHOUT(CKD PACKAGE)&TIRE & DISK WHEEL-195R15C 8PR(ALUMINUM),TYPE B:REFER ILLUST.
42601AWHEEL, DISC (FOR SPARE)
15X6JJ,TYPE A:REFER ILLUST.
15X6JJ,TYPE A:REFER ILLUST.
15X6JJ,TYPE A:REFER ILLUST.
main42611-26170iKDH202..TH; TRH201..ARL,SA;TRH213..GL..VN;TRH213..LHD..STD;KDH221,TRH201..5D;TRH213..RHD..(10S,16S);TRH223..GL..(CIS,GCC,SA);TRH223..STD..(ARL,GCC,GEN,TH);KDH212,TRH201..SG..(03S,10S,11S,16S)..5F;KDH200,222,TRH203..(03S,14S,15S,16S)..5F..(GCC,GEN,SA,TH);KDH201,202,203,220,223,LH20#,212,222,TRH221..(03S,06S,12S,14S,15S,16S)..(ARL,GCC,GEN,SA)200709-201008
15X6J,TIRE & DISK WHEEL-195R15C 8PR(ALUMINUM),TYPE B:REFER ILLUST.; 15X6J,WITHOUT(CKD PACKAGE)&TIRE & DISK WHEEL-195R15C 8PR(ALUMINUM),TYPE B:REFER ILLUST.
42601CNUT, HUB (FOR AXLE)
TYPE A:REFER ILLUST.
main90942-01058×24iTRH201..ARL,SA;TRH213..LHD..STD;KDH221,TRH201..5D;TRH213..RHD..(10S,16S);TRH223..GL..(CIS,GCC,SA);KDH212..(10S,11S,16S)..5F;TRH223..STD..(ARL,GCC,GEN,TH);KDH202,TRH213..5F..GL..(TH,VN);KDH202,TRH201..4D..SG..(GCC,GEN);KDH200,TRH203..(03S,15S)..5F..(GCC,GEN,SA,TH);KDH201,203,220,222,223,LH20#,212,222,TRH221..03S,06S,12S,14S,15S,16S200709-201008
TIRE & DISK WHEEL-195R15C 8PR(ALUMINUM),TYPE B:REFER ILLUST.
42603ORNAMENT SUB-ASSY, WHEEL HUB
main4260B-26010×4iKDH200..4FC;TRH223..GL..GEN;TRH203,213..(10S,12S)..GEN;KDH202,TRH201..RHD..(03S,12S)..STD..(GEN,TH);KDH212,221,LH212,TRH213..4D..(03S,10S,15S)..STD200709-201312
*ALU,TIRE & DISK WHEEL-195R15C 8PR(ALUMINUM),TYPE A:REFER ILLUST.
*ALU,TIRE & DISK WHEEL-195R15C 8PR(ALUMINUM),TYPE A:REFER ILLUST.
42611GVALVE (FOR TUBELESS TIRE)
main90942-05009×2iKDH202..RHD..SRF..GEN;KDH200,201,203,212,22#,LH20#,212,222,TRH20#,213,22#..RHD..(03S,06S,10S,11S,14S,15S,16S)..(ARL,GEN,SA,TH)200501-200701
42611JVALVE (FOR TUBELESS TIRE SPARE)
42621CAP, WHEEL
TYPE A:REFER ILLUST.
TYPE B:REFER ILLUST.
TYPE B:REFER ILLUST.
42652TIRE
295R15C-8PR,*B/S
main42652-26A60×2iKDH202..RHD..SRF..GEN;KDH222,TRH223..GL..SA;KDH222,223,TRH223..RHD..(ARL,GEN);KDH200,201,203,212,220,221,LH20#,212,222,TRH20#,213,221..RHD..(03S,06S,10S,11S,14S,15S,16S)..(ARL,GEN,SA,TH)200501-201312
195R15C-8PR,*B/S
195R15C-8PR,*T/Y
195R15C-8PR,*B/S
195R15C-8PR,*B/S
195R15C-8PR,*T/Y
main42652-26B41×2iKDH20#,212,220,222,223,LH20#,212,222,TRH201,203,213,22#..LHD..(CIS,GCC,GEN,RUS)201108-201312
195R15C-8PR,*T/Y
42652ATIRE (FOR SPARE)
295R15C-8PR,*B/S
195R15C-8PR,*B/S
195R15C-8PR,*T/Y
195R15C-8PR,*B/S
195R15C-8PR,*B/S
195R15C-8PR,*T/Y
main42652-26B41iKDH20#,212,220,222,223,LH20#,212,222,TRH201,203,213,22#..LHD..(CIS,GCC,GEN,RUS)201108-201312
195R15C-8PR,*T/Y
9 parts on this diagram · 2 diagrams in section
