HEATING & AIR CONDITIONING - COOLER PIPING

0001 1MEXICO SPEC 0002 1MEXICO,COSTARICA SPEC 0003 1 0004 1 0005 1MEXICO SPEC 0006 1 0007 1 0008 1 0009 1MEXICO,COSTARICA,NEW CALEDONI

88453FAN, COOLING (FOR CONDENSER)

main88453-60010iGRN245,265..DCB..5FC; GRN265..DCB201006-201109

MEXICO SPEC(W(VSC, SIDE & *CUSA)); MEXICO SPEC(W/O (VSC, SIDE & *CUSA))

88454ASHROUD, FAN

main88454-35080iGRN245,265..DCB..5FC; GRN265..DCB201006-201109

MEXICO SPEC(W(VSC, SIDE & *CUSA)); MEXICO SPEC(W/O (VSC, SIDE & *CUSA))

main88454-35090iGRN305,325..DCB..6FC..SR5201508-201711

MEXICO SPEC

main88454-35091iGRN305,325..DCB..6FC..SR5201909

MEXICO, COSTARICA SPEC

88550MOTOR ASSY, BLOWER (FOR CONDENSER)

main16363-64080iGRN245,265..DCB..5FC; GRN265..DCB201006-201109

MEXICO SPEC(W(VSC, SIDE & *CUSA)); MEXICO SPEC(W/O (VSC, SIDE & *CUSA))

88590BLOWER ASSY, W/SHROUD

main88590-35040iGRN245,265..DCB..5FC; GRN265..DCB201006-201109

MEXICO SPEC(W(VSC, SIDE & *CUSA)); MEXICO SPEC(W/O (VSC, SIDE & *CUSA))

main88590-35050iGRN305,325..DCB..6FC..SR5201508-201711

MEXICO SPEC

main88590-35051iGRN305,325..DCB..6FC..SR5201909

MEXICO, COSTARICA SPEC

88723BLABEL, COOLER SERVICE CAUTION

main16793-31070iGRN305,325..DCB..6FC..SR5201711-201909

MEXICO SPEC

main88723-20081iGRN245,265..DCB..5FC; GRN265..DCB201006-201109

MEXICO SPEC(W(VSC, SIDE & *CUSA)); MEXICO SPEC(W/O (VSC, SIDE & *CUSA))

827112B640WIRE, FUSE TO FUSE(FOR COMBUSTION HEATER)

main82711-2B640

8889735050VALVE, COOLER MAGNET

main88897-35050

8889760170VALVE, COOLER MAGNET

main88897-60170

8889760180VALVE, COOLER MAGNET

main88897-60180

8889771010VALVE, COOLER MAGNET

main88897-71010

9009904117

main90099-04117

9009904119

main90099-04119

90119A0078

main90119-A0078

13 parts on this diagram · 9 diagrams in section
