CAUTION PLATE (EXTERIOR & INTERIOR)

0001 1ENGINE ROOM 0002 1EXTERIOR & INTERIOR

11285KLABEL, COOLANT SYSTEM INFORMATION

main11285-10040iEM..XEBM15202301-202311

16793ELABEL, COOLING FAN CAUTION

main16793-36030iEM..XEBM15202301-202311

74558BLABEL, BATTERY INSPECTION INFORMATION

main74558-78010iXEBM15202301-202311

82685DPLATE, CAUTION

main82684-48010iXEBM1#202311

88723ELABEL, COOLER SERVICE CAUTION

main88723-42160iXEBM1#202311

main88723-76090supersedes 88723-42160iXEBM15202301-202311

KOREA SPEC

G9131LABEL, ELECTRIC VEHICLE EMISSION CONTROL INFORMATION

mainG913146010iXEBM15202301-202311

mainG913146020iXEBM15202311-202411

mainG913146030iXEBM10202311-202411

mainG913146140iXEBM10202411

mainG913146150iXEBM15202411

G9275LABEL, BATTERY CAUTION, NO.1

main288A2-10010iXEBM1#202311

7 parts on this diagram · 2 diagrams in section
