SWITCH & RELAY & COMPUTER

0001 1ENGINE & TRANSMISSION 0002 1ENGINE ROOM(1/2) 0003 1ENGINE ROOM(2/2) 0004 1COWL 0005 1COWL 0006 1INSTRUMENT PANEL(1/2) 0007 1INSTRUMENT PANEL(2/2) 0008 1INSTRUMENT PANEL(2/2) 0009 1STEERING 0010 1SEAT 0011 1DOOR,ROOF & FLOOR 0012 1FLOOR,LUGGAGE & BACK DOOR 0013 1FLOOR,LUGGAGE & BACK DOOR

83530SWITCH ASSY, OIL PRESSURE (FOR ENGINE)

main83530-0E010iGYL20201510-201909

(L),DENSO

main83530-28020iGGL2#,GYL25201510-201909

(J),DENSO

84540SWITCH ASSY, NEUTRAL START

main84540-48030iGGL2#201510-201909

89451ASENSOR, SHIFT LEVER POSITION

main89451-52040iGYL25201510-201909

89465SENSOR, OXYGEN

main89465-0E220iGGL2#201510-201909

main89465-0E230iGYL20201510-201909

89465ASENSOR, OXYGEN NO.2

main89465-0E210iGYL20201510-201909

89467BSENSOR, AIR FUEL RATIO

main89467-0E240iGYL20201510-201909

89467CSENSOR, AIR FUEL RATIO, NO.2

main89467-0E250iGYL20201510-201909

89491SENSOR, ENGINE OIL LEVEL

main89491-48020iGGL2#,GYL2#201510-201808

sub89491-48021

main89491-48021iGGL2#,GYL25201809-202004

sub89491-48040

main89491-48040iGGL2#202002-202204

sub89491-48041

main89491-48041iGGL2#202205

89615SENSOR, KNOCK CONTROL

main89615-06010iGGL2#201510-201909

main89615-20090iGYL25201510-201909

8271548A20BRACKET,WIRING HARNESS CLAMP

main82715-48A20

8271548M40BRACKET,WIRING HARNESS CLAMP

main82715-48M40

8271548M50BRACKET,WIRING HARNESS CLAMP

main82715-48M50

8271572040BRACKET,WIRING HARNESS CLAMP

main82715-72040

9010508376

main90105-08376

90105A0128

main90105-A0128

90119A0160

main90119-A0160

90119A0182

main90119-A0182

90178A0023

main90178-A0023

9046815007

main90468-15007

9155180830

main91551-80830

9165140620

main91651-40620

9415180600

main94151-80600

22 parts on this diagram · 13 diagrams in section
