THROTTLE LINK & VALVE LEVER (ATM)

Parts diagram

35056LEVER SUB-ASSY, PARKING LOCK W/ROLLER

main35057-33010i201204

35501ROD SUB-ASSY, PARKING LOCK

main35501-33020i200901-201204

main35501-48020i201207

35505LEVER SUB-ASSY, MANUAL VALVE

main35505-33011i200901-201203

main35505-48040i201207

35505GPIN, SLOTTED SPRING (FOR MANUAL VALVE LEVER)

main90254-04011×2i200901-201203

35506SHAFT SUB-ASSY, MANUAL VALVE LEVER

main35506-33020i201204

35506FSEAL, OIL (FOR MANUAL VALVE LEVER SHAFT)

main90311-12002i201207

main90311-A0009i200901-201204

35506HSPACER (FOR MANUAL VALVE LEVER SHAFT)

main90560-20006×2i200901-201203

35506JSPRING, RETAINER (FOR MANUAL VALVE LEVER SHAFT)

main90524-A0001i201204

35556SHAFT, PARKING LOCK PAWL

main35556-0R010i201411

main35556-33010i200901-201204

main35556-48020i201207

35556CSPRING, TORSION (FOR PARKING LOCK PAWL SHAFT)

main90508-A0008i200901-201204

35556HSHAFT, PARKING LOCK PAWL

main35556-0R020i201411

main35556-63010i200901-201204

35557PAWL, PARKING LOCK

main35557-33020i200901-201203

main35557-33021i201203-201204

main35557-48030i201207

35558CLAMP, PAWL SHAFT

main35558-06010i201212

main35558-33010i200901-201204

35561SHAFT, MANUAL VALVE LEVER

main35561-33020i200901-201203

35572ALEVER, TRANSMISSION CONTROL SHAFT

main35572-07020i200901-200908

main35572-08020i200908-201204

main35572-48040i201207-201510

35596PLATE, PAWL STOPPER

main35596-07010i200901-201204

35596ABOLT (FOR PAWL STOPPER PLATE)

main90080-10400×2i201204

*8-1.25PX16-13.5

35598SLEEVE, PARKING LOCK

main35598-0R010i201212

main35598-33010i200901-201204

8401SWITCH & RELAY & COMPUTER

→ Go to FIG 84-01

9008010400

main90080-10400

90170A0001

main90170-A0001

9451200800

main94512-00800

22 parts on this diagram · 3 diagrams in section
