THROTTLE LINK & VALVE LEVER (ATM)

35501ROD SUB-ASSY, PARKING LOCK

main35501-07010iMCU33..NAP200407-200602

main35501-21010iMCU33..NAP200309-200407

35505LEVER SUB-ASSY, MANUAL VALVE

main35505-21010iMCU3#..NAP200309-200602

35505BSPACER (FOR MANUAL VALVE LEVER)

main90560-20006iMCU3#..NAP200309-200602

35505GPIN, SLOTTED SPRING (FOR MANUAL VALVE LEVER)

main90254-04011iGSU3#..NAP200602

35506FSEAL, OIL (FOR MANUAL VALVE LEVER SHAFT)

main90311-12002iGSU3#..NAP200602

35506JSPRING, RETAINER (FOR MANUAL VALVE LEVER SHAFT)

main90524-09001iMCU3#..NAP200309-200602

35556SHAFT, PARKING LOCK PAWL

main35556-07010iGSU3#..NAP200602-200708

main35556-21010iGSU3#..NAP200708

main35556-28010iMCU3#..NAP200309-200511

35557PAWL, PARKING LOCK

main35590-21010iGSU30..NAP200602

35557ASPRING, TORSION (FOR PARKING LOCK PAWL)

main90080-50373iMCU3#..NAP200309-200602

(L)

main90506-18077iMCU33..NAP200309-200602

(J)

35558CLAMP, PAWL SHAFT

main35558-21010iGSU3#..NAP200602

35561SHAFT, MANUAL VALVE LEVER

main35561-21010iMCU3#..NAP200309-200602

35572ALEVER, TRANSMISSION CONTROL SHAFT

main35572-08010iMCU3#..NAP200309-200602

(L)

main35572-48010iMCU3#..NAP200309-200602

(J)

35579PIN, PARKING LOCK PAWL

main35594-07010iMCU3#..NAP200511-200602

main35594-21010iMCU3#..NAP200309-200511

35595BRACKET, PARKING LOCK PAWL

main35595-21010iMCU3#..NAP200309-200602

8401SWITCH & RELAY & COMPUTER

→ Go to FIG 84-01

8404ELECTRONIC FUEL INJECTION SYSTEM

→ Go to FIG 84-04

9008010164

main90080-10164

9008011493

main90080-11493

9008011497

main90080-11497

90170A0001

main90170-A0001

90204A0001

main90204-A0001

9451200800

main94512-00800

22 parts on this diagram · 1 diagram in section
