52133JREINFORCEMENT, FRONT BUMPER BAR, RH

main52133-50050i200704-200809

main52133-50060i200911

52134JREINFORCEMENT, FRONT BUMPER BAR, LH

main52134-50050i200704-200809

main52134-50060i200911

81107COMPUTER SUB-ASSY, HEADLAMP LIGHT CONTROL, RH

main81107-22A10i200911-201009

KOREA SPEC; USA POSSESSIONS SPEC

main81107-50380supersedes 81107-50590i200704-200809

HEADLAMP-LED & HALOGEN & *AFLS; PRE-COLLISION SYSTEM-WITH(*STC & *DMO & *PB)&HEADLAMP-LED & HALOGEN & *AFLS & INFRARED&REAR SEAT ADJUSTER-OTTOMAN; PRE-COLLISION SYSTEM-WITH(*STC & *DMO & *PB)&HEADLAMP-LED & HALOGEN & *AFLS & INFRARED&REAR SEAT ADJUSTER-SEPARATE W/POWER SLIDE

81108COMPUTER SUB-ASSY, HEADLAMP LIGHT CONTROL, LH

main81107-22A10i200911-201009

KOREA SPEC; USA POSSESSIONS SPEC

main81107-50380supersedes 81107-50590i200704-200809

HEADLAMP-LED & HALOGEN & *AFLS; PRE-COLLISION SYSTEM-WITH(*STC & *DMO & *PB)&HEADLAMP-LED & HALOGEN & *AFLS & INFRARED&REAR SEAT ADJUSTER-OTTOMAN; PRE-COLLISION SYSTEM-WITH(*STC & *DMO & *PB)&HEADLAMP-LED & HALOGEN & *AFLS & INFRARED&REAR SEAT ADJUSTER-SEPARATE W/POWER SLIDE

81110HEADLAMP ASSY, RH

main81110-50420i200809-200902

HEADLAMP-LED & HALOGEN & *AFLS

main81110-50421i200903-200907

HEADLAMP-LED & HALOGEN & *AFLS

main81110-50422i200908-200911

HEADLAMP-LED & HALOGEN & *AFLS

main81110-50430i200704-200809

PRE-COLLISION SYSTEM-WITH(*STC & *DMO & *PB)&HEADLAMP-LED & HALOGEN & *AFLS & INFRARED&REAR SEAT ADJUSTER-OTTOMAN; PRE-COLLISION SYSTEM-WITH(*STC & *DMO & *PB)&HEADLAMP-LED & HALOGEN & *AFLS & INFRARED&REAR SEAT ADJUSTER-SEPARATE W/POWER SLIDE

main81110-50431i200903-200907

PRE-COLLISION SYSTEM-WITH(*STC & *DMO & *PB)&HEADLAMP-LED & HALOGEN & *AFLS & INFRARED&REAR SEAT ADJUSTER-OTTOMAN; PRE-COLLISION SYSTEM-WITH(*STC & *DMO & *PB)&HEADLAMP-LED & HALOGEN & *AFLS & INFRARED&REAR SEAT ADJUSTER-SEPARATE W/POWER SLIDE

main81110-50432i200908-200911

PRE-COLLISION SYSTEM-WITH(*STC & *DMO & *PB)&HEADLAMP-LED & HALOGEN & *AFLS & INFRARED&REAR SEAT ADJUSTER-OTTOMAN; PRE-COLLISION SYSTEM-WITH(*STC & *DMO & *PB)&HEADLAMP-LED & HALOGEN & *AFLS & INFRARED&REAR SEAT ADJUSTER-SEPARATE W/POWER SLIDE

main81110-50580supersedes 81110-50570i200911-201108

PRE-COLLISION SYSTEM-WITH(*DMO & *PB & *STC)

main81110-50581supersedes 81110-50571i201108

PRE-COLLISION SYSTEM-WITH(*DMO & *PB & *STC)

81110BBULB(FOR HEADLAMP, NO.1)

main90080-81041×2supersedes 90981-13046i200902-200903

12V 65W,HEADLAMP-LED & HALOGEN & *AFLS; 12V 65W,PRE-COLLISION SYSTEM-WITH(*STC & *DMO & *PB)&HEADLAMP-LED & HALOGEN & *AFLS & INFRARED&REAR SEAT ADJUSTER-OTTOMAN; 12V 65W,PRE-COLLISION SYSTEM-WITH(*STC & *DMO & *PB)&HEADLAMP-LED & HALOGEN & *AFLS & INFRARED&REAR SEAT ADJUSTER-SEPARATE W/POWER SLIDE

81110LBULB, DISCHARGE HEADLAMP

main90981-20013×2i200704-200801

45V 35W

main90981-20021×2i200802-200809

45V 35W

main90981-20024×2i200902-200911

42V 35W

81116CBRACKET, HEADLAMP, RH

main81116-50280i200704-200809

main81116-50530i200911

81129AREFLECTOR, HEADLAMP, RH

main81129-33680i200704-200809

main81129-50381i200911

81132BGASKET, HEADLAMP LENS

main81132-50340×2i200704-200809

main81132-50530×2i200911

81134GASKET, HEADLAMP

main90075-68007i200704-200809

81135UNIT ASSY, HEADLAMP, RH

main81145-50320supersedes 81145-50451i200704-200809

PRE-COLLISION SYSTEM-WITH(*STC & *DMO & *PB)&HEADLAMP-DISCHARGE & HALOGEN & *AFLS& INFRARED&REAR SEAT ADJUSTER-OTTOMAN; PRE-COLLISION SYSTEM-WITH(*STC & *DMO & *PB)&HEADLAMP-DISCHARGE & HALOGEN & *AFLS& INFRARED&REAR SEAT ADJUSTER-SEPARATE W/POWER SLIDE

main81145-50420supersedes 81145-50451i200704-200809

HEADLAMP-LED & HALOGEN & *AFLS

main81145-50421supersedes 81145-50451i200903-200908

HEADLAMP-LED & HALOGEN & *AFLS

main81145-50422supersedes 81145-50451i200908-200911

HEADLAMP-LED & HALOGEN & *AFLS

main81145-50430supersedes 81145-50451i200704-200809

PRE-COLLISION SYSTEM-WITH(*STC & *DMO & *PB)&HEADLAMP-LED & HALOGEN & *AFLS & INFRARED&REAR SEAT ADJUSTER-OTTOMAN; PRE-COLLISION SYSTEM-WITH(*STC & *DMO & *PB)&HEADLAMP-LED & HALOGEN & *AFLS & INFRARED&REAR SEAT ADJUSTER-SEPARATE W/POWER SLIDE

main81145-50431supersedes 81145-50451i200903-200908

PRE-COLLISION SYSTEM-WITH(*STC & *DMO & *PB)&HEADLAMP-LED & HALOGEN & *AFLS & INFRARED&REAR SEAT ADJUSTER-OTTOMAN; PRE-COLLISION SYSTEM-WITH(*STC & *DMO & *PB)&HEADLAMP-LED & HALOGEN & *AFLS & INFRARED&REAR SEAT ADJUSTER-SEPARATE W/POWER SLIDE

main81145-50432supersedes 81145-50451i200908-200911

PRE-COLLISION SYSTEM-WITH(*STC & *DMO & *PB)&HEADLAMP-LED & HALOGEN & *AFLS & INFRARED&REAR SEAT ADJUSTER-OTTOMAN; PRE-COLLISION SYSTEM-WITH(*STC & *DMO & *PB)&HEADLAMP-LED & HALOGEN & *AFLS & INFRARED&REAR SEAT ADJUSTER-SEPARATE W/POWER SLIDE

main81145-50580supersedes 81145-50570i200911-201108

PRE-COLLISION SYSTEM-WITH(*DMO & *PB & *STC)

main81145-50581supersedes 81145-50571i201108

PRE-COLLISION SYSTEM-WITH(*DMO & *PB & *STC)

main81145-50630i200911-201009

KOREA SPEC; USA POSSESSIONS SPEC

81135ACAP, LOCKING

main90075-66004×2i200809-200911

HEADLAMP-LED & HALOGEN & *AFLS; PRE-COLLISION SYSTEM-WITH(*STC & *DMO & *PB)&HEADLAMP-LED & HALOGEN & *AFLS & INFRARED&REAR SEAT ADJUSTER-OTTOMAN; PRE-COLLISION SYSTEM-WITH(*STC & *DMO & *PB)&HEADLAMP-LED & HALOGEN & *AFLS & INFRARED&REAR SEAT ADJUSTER-SEPARATE W/POWER SLIDE

81136DCOVER, HEADLAMP

main81136-50340×2i200903-200911

81156ABRACKET, HEADLAMP, LH

main81156-50280supersedes 81156-50530i200903-200911

HEADLAMP-LED & HALOGEN & *AFLS; PRE-COLLISION SYSTEM-WITH(*STC & *DMO & *PB)&HEADLAMP-LED & HALOGEN & *AFLS & INFRARED&REAR SEAT ADJUSTER-OTTOMAN; PRE-COLLISION SYSTEM-WITH(*STC & *DMO & *PB)&HEADLAMP-LED & HALOGEN & *AFLS & INFRARED&REAR SEAT ADJUSTER-SEPARATE W/POWER SLIDE

81169REFLECTOR, HEADLAMP, LH

main81169-50381i200903-200911

HEADLAMP-LED & HALOGEN & *AFLS; PRE-COLLISION SYSTEM-WITH(*STC & *DMO & *PB)&HEADLAMP-LED & HALOGEN & *AFLS & INFRARED&REAR SEAT ADJUSTER-OTTOMAN; PRE-COLLISION SYSTEM-WITH(*STC & *DMO & *PB)&HEADLAMP-LED & HALOGEN & *AFLS & INFRARED&REAR SEAT ADJUSTER-SEPARATE W/POWER SLIDE

81175UNIT ASSY, HEADLAMP, LH

main81185-50320supersedes 81185-50451i200704-200809

PRE-COLLISION SYSTEM-WITH(*STC & *DMO & *PB)&HEADLAMP-DISCHARGE & HALOGEN & *AFLS& INFRARED&REAR SEAT ADJUSTER-OTTOMAN; PRE-COLLISION SYSTEM-WITH(*STC & *DMO & *PB)&HEADLAMP-DISCHARGE & HALOGEN & *AFLS& INFRARED&REAR SEAT ADJUSTER-SEPARATE W/POWER SLIDE

main81185-50420supersedes 81185-50451i200704-200809

HEADLAMP-LED & HALOGEN & *AFLS

main81185-50421supersedes 81185-50451i200903-200908

HEADLAMP-LED & HALOGEN & *AFLS

main81185-50422supersedes 81185-50451i200908-200911

HEADLAMP-LED & HALOGEN & *AFLS

main81185-50430supersedes 81185-50451i200704-200809

PRE-COLLISION SYSTEM-WITH(*STC & *DMO & *PB)&HEADLAMP-LED & HALOGEN & *AFLS & INFRARED&REAR SEAT ADJUSTER-OTTOMAN; PRE-COLLISION SYSTEM-WITH(*STC & *DMO & *PB)&HEADLAMP-LED & HALOGEN & *AFLS & INFRARED&REAR SEAT ADJUSTER-SEPARATE W/POWER SLIDE

main81185-50431supersedes 81185-50451i200903-200908

PRE-COLLISION SYSTEM-WITH(*STC & *DMO & *PB)&HEADLAMP-LED & HALOGEN & *AFLS & INFRARED&REAR SEAT ADJUSTER-OTTOMAN; PRE-COLLISION SYSTEM-WITH(*STC & *DMO & *PB)&HEADLAMP-LED & HALOGEN & *AFLS & INFRARED&REAR SEAT ADJUSTER-SEPARATE W/POWER SLIDE

main81185-50432supersedes 81185-50451i200908-200911

PRE-COLLISION SYSTEM-WITH(*STC & *DMO & *PB)&HEADLAMP-LED & HALOGEN & *AFLS & INFRARED&REAR SEAT ADJUSTER-OTTOMAN; PRE-COLLISION SYSTEM-WITH(*STC & *DMO & *PB)&HEADLAMP-LED & HALOGEN & *AFLS & INFRARED&REAR SEAT ADJUSTER-SEPARATE W/POWER SLIDE

main81185-50580supersedes 81185-50570i200911-201108

PRE-COLLISION SYSTEM-WITH(*DMO & *PB & *STC)

main81185-50581supersedes 81185-50571i201108

PRE-COLLISION SYSTEM-WITH(*DMO & *PB & *STC)

main81185-50630i200911-201009

KOREA SPEC; USA POSSESSIONS SPEC

81193RETAINER, HEADLAMP PROTECTOR, UPPER RH

main81193-50020i200704-200809

81193APROTECTOR, HEADLAMP, RH

main81193-50030i200704-200809

81194RETAINER, HEADLAMP PROTECTOR, UPPER LH

main81194-50020i200704-200809

81194APROTECTOR, HEADLAMP, LH

main81193-50030i200704-200809

81195ARETAINER, HEADLAMP PROTECTOR, LOWER RH

main81195-50020i200704-200809

81196ARETAINER, HEADLAMP PROTECTOR, LOWER LH

main81196-50020i200704-200809

81510CBULB (FOR FRONT TURN SIGNAL LAMP)

main90981-15021×2i200704-200809

12V 21W,AMBER

81610FBULB(FOR CLEARANCE LAMP)

main99132-12050×2i200704-200809

12V 5W

81615DSOCKET, CLEARANCE LAMP

main90075-60081×2i200704-200809

81710FBULB, FRONT SIDE MAKER LAMP

main90981-11020×2i200704-200809

81715BSOCKET & WIRE, FRONT SIDE MARKER LAMP

main90075-60077×2i200704-200809

8505HEADLAMP CLEANER

→ Go to FIG 85-05

85661MOTOR, HEADLAMP LEVELING, RH

main85661-28010i200704-200809

main85661-28011i200903-200911

85662MOTOR, HEADLAMP LEVELING, LH

main85691-28010i200704-200809

main85691-28011i200903-200911

85669PACKING, HEADLAMP LEVELING MOTOR BASE

main90075-99120×2i200704-200809

8111950280SCREW, HEADLAMP

main81119-50280

9007501017

main90075-01017

9007502054

main90075-02054

9007502056

main90075-02056

9010506298

main90105-06298

9010906293

main90109-06293
