OIL COOLER & TUBE (ATM)

0001 1A340E 0002 1A340E 0003 1A650E 0004 1A340E

32921TUBE, OIL COOLER INLET, NO.1

main32921-24130iJZZ31..4FC199108-199709

main32921-24150iUZZ30199104-199709

main32921-24200iJZZ31199709

main32921-24210iUZZ30199709

32921CUNION(FOR OIL COOLER TUBE)

main90404-16029iUZZ30199110-199307

FRONT

main90404-16030iJZZ31..4FC199110-199307

FRONT

main90407-16009iUZZ30199110-199307

REAR

main90407-16033iJZZ31..4FC199110-199307

REAR

32921DHOSE(FOR OIL COOLER INLET)

main32942-35011iJZZ31..4FC199302-199505

main90445-17096iJZZ31..4FC199108-199302

main90445-17100iJZZ31199709

main90445-17103iUZZ30199104

main90445-17124iJZZ31..4FC199505-199709

32921GRING, O(FOR OIL COOLER TUBE UNION)

main90301-11006×2iJZZ31,UZZ30..ATM199104-200007

32921JCLIP(FOR OIL COOLER HOSE)

main90467-16013×4iJZZ31,UZZ30..4FC199104-199608

32922TUBE, OIL COOLER OUTLET, NO.1

main32922-24140iJZZ31..4FC199108-199709

main32922-24160iUZZ30199104-199709

main32922-24210iJZZ31199709

main32922-24220iUZZ30199709

32922AHOSE(FOR OIL COOLER OUTLET)

main32941-22201iJZZ31..4FC199302-199505

main32942-22161iUZZ30199104

main90445-17095iJZZ31..4FC199108-199302

main90445-17100iJZZ31..4FC199505-199709

main90445-17104iJZZ31199709

32923ACLAMP, AUTOMATIC TRANSMISSION OIL COOLER TUBE

main32929-24070iJZZ31..4FC199108

main90462-12074iUZZ30199104-199709

32923BCLAMP, AUTOMATIC TRANSMISSION OIL COOLER TUBE, NO.1

main32923-50010iUZZ30199104

main32929-24060iJZZ31..4FC199108

32923CCLAMP, AUTOMATIC TRANSMISSION OIL COOLER TUBE, NO.4

main32924-22090iJZZ31..4FC199108

main32924-50011iUZZ30199104-199709

32924CLAMP, OIL COOLER TUBE, NO.2

main32923-30160iJZZ31..4FC199108-199301

main32923-30161iJZZ31..4FC199301-199709

main32923-50030iUZZ30199709

NO.1

main32924-24050iUZZ30199104-199709

main32924-30230iJZZ31199709

main32924-50020iUZZ30199709

NO.2

32926CUSHION, OIL COOLER TUBE(ATM)

main32926-30020×6iJZZ31..4FC199108-199709

L=35,ID=10

main32926-30030×2iJZZ31199709

NO.2

32928CLAMP, FLEXIBLE HOSE, NO.1

main32928-24020iUZZ30199104-199709

9161160612

main91611-60612

9161160814

main91611-60814

15 parts on this diagram · 4 diagrams in section
