CAUTION PLATE (EXTERIOR & INTERIOR)

0001 1ENGINE ROOM(1/2), EXTERIOR(1/0002 1ENGINE ROOM, EXTERIOR, INTERI

11289BLABEL, SPARK PLUG NOTICE

main11289-50010i2AZFE,1MZFE..ACV30,MCV30..JPP..ATM200107-200307

11296DLABEL, ENGINE SERVICE INFORMATION

main11296-27020i2AZFE,1MZFE,3MZFE..ACV30,MCV3#..JPP200310-200406

13564LABEL, TIMING BELT REPLACEMENT INFORMATION

main13564-10010i1MZFE..MCV30..JPP200107-200309

16793BLABEL, COOLING FAN INFORMATION

main16793-28010i2AZFE,3MZFE..ACV30,MCV31..JPP200107-200406

main16793-50010i2AZFE..ACV30..JPP200411-200601

TYPE B:REFER ILLUST.

17792CLABEL, ENGINE VACUUM HOSE INFORMATION

main17792-20230i1MZFE..MCV30..JPP200107-200301

main17792-20240i1MZFE..MCV30..JPP200301-200307

main17792-20270i3MZFE..MCV31..JPP200307-200406

main17792-20280i1MZFE..MCV30..JPP200307-200406

main17792-28150i2AZFE..ACV30..JPP..5F200307-200406

main17792-28170i2AZFE..ACV30..JPP200107-200307

5 parts on this diagram · 2 diagrams in section
