DISC WHEEL & WHEEL CAP

0001 1 0002 1

42601WHEEL, DISC

main42611-33010×4iMCV10..USA199603-199605

15X6JJ,OFFSET 45,#,COACH EDITION,TYPE A

main42611-33030×4iMCV10,VCV10199107-199608

15X6JJ,#,TYPE B

main42611-33090×4iMCV10..CND; MCV10..USA199408-199608

15X7JJ,TYPE B,W(CHROME PLATED WHEEL)

42601AWHEEL, DISC (FOR SPARE)

main42611-33010-01iMCV10,VCV10199107-199608

15X6JJ,OFFSET 45,#,BLACK

42601CNUT, HUB (FOR AXLE)

main90942-01007×20iMCV10..USA199603-199605

COACH EDITION

main90942-01050×20iMCV10,VCV10199107-199608

42603ORNAMENT SUB-ASSY, WHEEL HUB

main42603-33010×4iMCV10,VCV10199107-199608

main42603-33050×4iMCV10199408-199608

W(CROME PLATED WHEEL)

42611GVALVE (FOR TUBELESS TIRE)

main90942-05009×4iMCV10,VCV10199107-199608

main90942-05028×4iMCV10..CND; MCV10..USA199505-199608

W(CROME PLATED WHEEL)

42611JVALVE (FOR TUBELESS TIRE SPARE)

main90942-05009iMCV10,VCV10199107-199608

42611UCAP, TIRE VALVE

main90942-05029×4iMCV10199505-199608

42652TIRE

main42652-33090×4iMCV10,VCV10..USA199107-199608

P205/65R15 92V

42652ATIRE (FOR SPARE)

main42652-33090iMCV10,VCV10..USA199107-199608

P205/65R15 92V

9 parts on this diagram · 2 diagrams in section
