MANIFOLD
17111MANIFOLD, INTAKE
17111APLUG, NO.1
17111BPLUG, NO.2
17118STAY, MANIFOLD
17125STAY, SURGE TANK, NO.1
17129TANK, INTAKE AIR SURGE
17141MANIFOLD, EXHAUST
17141DBOLT, STUD(FOR OXYGEN SENSOR)
17152BOLT, STUD(FOR MANIFOLD TO EXHAUST PIPE)
17159BOLT, STUD(FOR MANIFOLD TO CYLINDER HEAD)
INTAKE SIDE
EXHAUST SIDE
EXHAUST SIDE
EXHAUST SIDE
INTAKE SIDE
17167INSULATOR, EXHAUST MANIFOLD HEAT, NO.1
17168INSULATOR, EXHAUST MANIFOLD HEAT, NO.2
17173GASKET, EXHAUST MANIFOLD TO HEAD
17177GASKET, INTAKE MANIFOLD TO HEAD, NO.1
25508CONVERTER SUB-ASSY, MANIFOLD
25508ABOLT, STUD(FOR MANIFOLD CONVERTER)
25576GASKET, MANIFOLD CONVERTER
25586INSULATOR, MANIFOLD CONVERTER, NO.1
25587INSULATOR, MANIFOLD CONVERTER, NO.2
25591BRACKET, MANIFOLD SUPPORT
9010508084
main90105-08084
9010510225
main90105-10225
9011608267
main90116-08267
9011610016
main90116-10016
9011908374
main90119-08374
9011910118
main90119-10118
9017908044
main90179-08044
9017908056
main90179-08056
9017908072
main90179-08072
9017910037
main90179-10037
9034114010
main90341-14010
9161160825
main91611-60825
9165160614
main91651-60614
9165160820
main91651-60820
9165161020
main91651-61020
36 parts on this diagram · 2 diagrams in section
