PLANETARY GEAR, REVERSE PISTON & COUNTER GEAR(ATM)

35071SHAFT SUB-ASSY, PLANETARY INTERMEDIATE

main35708-22011iMA46,RA42..(3FC,5F)..(LT,SPR)197708-198008

main35708-30020iMA46,RA42..(3FC,5F)..(LT,SPR)197901-197904

main35708-30021iRA43..CP..5F..GT;MA46,RA42..(3FC,5F)..(LT,SPR)197904-198107

main35708-30040iRA43..CP..5F..GT198008-198107

35074GEAR SUB-ASSY, REAR PLANETARY RING

main35074-22010iMA46,RA42..(3FC,5F)..(LT,SPR)197708-198008

main35074-30010iRA43..CP..5F..GT;MA46,RA42..(3FC,5F)..(LT,SPR)197901-198107

main35074-30020iRA43..CP..5F..GT198008-198107

35074ARING, SET (FOR REAR PLANETARY RING GEAR)

main90522-20037iRA43..CP..5F..GT;MA46,RA42..(3FC,5F)..(LT,SPR)197708-198107

35074BRACE, THRUST BEARING (FOR REAR PLANETARY RING GEAR FRONT)

main35789-22050iRA43..CP..5F..GT;MA46,RA42..(3FC,5F)..(LT,SPR)197708-198107

35074CRACE, THRUST BEARING (FOR REAR PLANETARY RING GEAR REAR)

main35789-22020iRA43..CP..5F..GT;MA46,RA42..(3FC,5F)..(LT,SPR)197708-198107

35074DBEARING, THRUST (FOR REAR PLANETARY RING GEAR REAR)

main90374-28014iRA43..CP..5F..GT;MA46,RA42..(3FC,5F)..(LT,SPR)197708-198107

35481TGEAR, SPEEDMETER DRIVE (ATM)

main33481-20030iRA42..3FC197708-197901

main33481-20100iRA43..4FC..ST198008-198107

main33481-26010iMA46,RA42..ATM197901-198008

N=6,MARK 6X18-20

35481UKEY OR BALL, SPEEDMETER DRIVE GEAR (ATM)

main90280-03005iRA42..3FC197708-197901

main90360-06004iMA4#,RA4#..ATM197901-198107

35481VRING OR SPACER (FOR ATM SPEEDMETER DRIVE GEAR)

main90520-28009×2iMA4#,RA4#..ATM197708-198107

T=1.50,OD=33.8

35702CARRIER SUB-ASSY, PLANETARY W/LOCK GEAR

main35704-30020iRA43..CP..5F..GT;MA46,RA42..(3FC,5F)..(LT,SPR)197901-198107

main35704-30030iRA43..CP..5F..GT198008-198107

35706FRACE, THRUST BEARING (FOR SUN GEAR REAR)

main35789-22010iRA43..CP..5F..GT;MA46,RA42..(3FC,5F)..(LT,SPR)197708-198107

35706GBEARING, THRUST (FOR SUN GEAR REAR)

main90374-23012iRA43..CP..5F..GT;MA46,RA42..(3FC,5F)..(LT,SPR)197708-198107

35720GEAR ASSY, FRONT PLANETARY

main35720-22011iMA46,RA42..(3FC,5F)..(LT,SPR)197708-198008

35735RING, PLANETARY OUTPUT SNAP

main35735-22010×3iRA43..CP..5F..GT;MA46,RA42..(3FC,5F)..(LT,SPR)197708-198107

35737WASHER, PLANETARY CARRIER THRUST

main35737-22010iRA43..CP..5F..GT;MA46,RA42..(3FC,5F)..(LT,SPR)197708-198107

main35737-30020iRA43..CP..5F..GT198008-198107

35738WASHER, PLANETARY CARRIER THRUST, NO.2

main35738-22010iRA43..CP..5F..GT;MA46,RA42..(3FC,5F)..(LT,SPR)197708-198107

main35738-30010iRA43..CP..5F..GT198008-198107

35739WASHER, PLANETARY CARRIER THRUST, NO.3

main35739-22011iRA43..CP..5F..GT;MA46,RA42..(3FC,5F)..(LT,SPR)197708-198107

main35739-30010iRA43..CP..5F..GT198008-198107

35743GEAR, FRONT PLANETARY RING

main35743-22010iRA43..CP..5F..GT;MA46,RA42..(3FC,5F)..(LT,SPR)197708-198107

main35743-30010iRA43..CP..5F..GT198008-198107

35743ARING, SHAFT SNAP (FOR FRONT PLANETARY RING GEAR)

main90520-99121iRA43..CP..5F..GT;MA46,RA42..(3FC,5F)..(LT,SPR)197708-198107

35748RING, INTERMEDIATE SHAFT SLEEVE OIL SEAL

main35748-30010iRA43..CP..5F..GT;MA46,RA42..(3FC,5F)..(LT,SPR)197901-198107

35760GEAR ASSY, REAR PLANETARY

main35760-20010iMA46,RA42..(3FC,5F)..(LT,SPR)197708-198008

main35760-30010iRA43..CP..5F..GT198008-198107

main35760-30020iMA46,RA42..(3FC,5F)..(LT,SPR)197901-198008

main35760-30030iRA43..CP..5F..GT198008-198107

35770SHAFT ASSY, OUTPUT

main35770-22010iRA42..3FC..LT197708-197901

main35770-22011iMA46,RA42..(3FC,5F)..(LT,SPR)197901-197910

main35770-22012iRA43..CP..5F..GT;MA46,RA42..(3FC,5F)..(LT,SPR)197910-198107

main35770-30010iRA43..CP..5F..GT198008-198107

main35770-30021iMA46,RA42..(3FC,5F)..(LT,SPR)197901-197910

main35770-30022iMA46,RA42..(3FC,5F)..(LT,SPR)197910-198008

35770ABEARING, THRUST (FOR OUTPUT SHAFT)

main90374-38013iRA43..CP..5F..GT;MA46,RA42..(3FC,5F)..(LT,SPR)197708-198107

35770BRACE, THRUST BEARING (FOR OUTPUT SHAFT)

main35789-22040iRA43..CP..5F..GT;MA46,RA42..(3FC,5F)..(LT,SPR)197708-198107

35792CLUTCH, 1 WAY, NO.2

main35792-20010iRA43..CP..5F..GT198008-198107

main35792-22020iMA46,RA42..(3FC,5F)..(LT,SPR)197708-198008

main35792-22030iMA46,RA42..(3FC,5F)..(LT,SPR)197901-198008

main35792-30010iRA43..CP..5F..GT198008-198107

35792BRING, HOLE SNAP (FOR 1 WAY CLUTCH NO.2)

main90521-79148iRA43..CP..5F..GT;MA46,RA42..(3FC,5F)..(LT,SPR)197708-198107

26 parts on this diagram · 1 diagram in section
