CENTER SUPPORT & PLANETARY SUN GEAR (ATM)

0001 1 0002 1

35620SUPPORT ASSY, CENTER

main35620-22030iRA42..3FC..LT197708-197802

35620APLATE, CLUTCH (FOR BRAKE)

main35634-22060×3iRA43..CP..5F..GT;MA46,RA42..(3FC,5F)..(LT,SPR)197708-198107

T=1.8,NSK-WARNER

main35634-22090iMA46,RA42..(3FC,5F)..(LT,SPR)197708-198008

AISIN CHEMICAL

main35648-30010×3iRA43..CP..5F..GT;MA46,RA42..(3FC,5F)..(LT,SPR)197901-198107

T=2.0,NSK-WARNER

35620BDISC, CLUTCH (FOR BRAKE)

main35677-22020×3iRA43..CP..5F..GT;MA46,RA42..(3FC,5F)..(LT,SPR)197708-198107

NSK-WARNER

main35677-22030iMA46,RA42..(3FC,5F)..(LT,SPR)197708-198008

AISIN CHEMICAL

35620CFLANGE, CLUTCH (FOR BRAKE)

main34625-22010iRA43..CP..5F..GT;MA46,RA42..(3FC,5F)..(LT,SPR)197901-198107

main35675-22010iRA43..CP..5F..GT;MA46,RA42..(3FC,5F)..(LT,SPR)197708-198107

35620DRING (FOR BRAKE)

main90521-99139iRA43..CP..5F..GT;MA46,RA42..(3FC,5F)..(LT,SPR)197708-198107

35620RPLATE, CLUTCH (FOR REAR BRAKE)

main35634-22060×3iMA46,RA42..(3FC,5F)..(LT,SPR)197708-198008

NSK-WARNER

main35634-22090×3iMA46,RA42..(3FC,5F)..(LT,SPR)197708-198008

AISIN CHEMICAL

main35648-30020×3iRA43..CP..5F..GT198008-198107

AISIN CHEMICAL

35620SDISC, CLUTCH (FOR REAR BRAKE)

main35677-22040×2iRA43..CP..5F..GT;MA46,RA42..(3FC,5F)..(LT,SPR)197708-198107

35620TFLANGE, CLUTCH (FOR REAR BRAKE)

main35675-22010iRA43..CP..5F..GT;MA46,RA42..(3FC,5F)..(LT,SPR)197708-198107

35620URING (FOR REAR BRAKE)

main90521-99139iRA43..CP..5F..GT;MA46,RA42..(3FC,5F)..(LT,SPR)197708-198107

35621PISTON, BRAKE, NO.1

main35621-22010iMA46,RA42..(3FC,5F)..(LT,SPR)197708-198008

main35621-30010iRA43..CP..5F..GT;MA46,RA42..(3FC,5F)..(LT,SPR)197901-198107

main35624-22010iRA43..CP..5F..GT198008-198107

35621ARING, O (FOR BRAKE PISTON OUTER)

main90301-99007iRA43..CP..5F..GT;MA46,RA42..(3FC,5F)..(LT,SPR)197901-198107

main90301-99192iRA43..CP..5F..GT;MA46,RA42..(3FC,5F)..(LT,SPR)197708-198107

35621BRING, O (FOR BRAKE PISTON INNER)

main90301-57188iRA43..CP..5F..GT;MA46,RA42..(3FC,5F)..(LT,SPR)197708-198107

35621CSPRING (FOR BRAKE PISTON RETURN)

main90501-10671×20iRA43..CP..5F..GT;MA46,RA42..(3FC,5F)..(LT,SPR)197708-198107

35621RPISTON, BRAKE (FOR REAR BRAKE)

main35621-22010iMA46,RA42..(3FC,5F)..(LT,SPR)197708-198008

main35621-30010iRA43..CP..5F..GT198008-198107

35621SRING (FOR REAR BRAKE PISTON OUTER)

main90301-99007iRA43..CP..5F..GT198008-198107

main90301-99192iMA46,RA42..(3FC,5F)..(LT,SPR)197708-198008

35621TRING (FOR REAR BRAKE PISTON INNER)

main90301-57188iRA43..CP..5F..GT;MA46,RA42..(3FC,5F)..(LT,SPR)197708-198107

35621USPRING (FOR REAR BRAKE PISTON RETURN)

main90501-10671×20iRA43..CP..5F..GT;MA46,RA42..(3FC,5F)..(LT,SPR)197708-198107

35627SEAT, BRAKE RETURN SPRING

main35627-22010iRA43..CP..5F..GT;MA46,RA42..(3FC,5F)..(LT,SPR)197708-198107

35627ARING, SHAFT SNAP (FOR BRAKE RETURN SPRING SEAT)

main90520-52262iRA43..CP..5F..GT;MA46,RA42..(3FC,5F)..(LT,SPR)197708-198107

35627RSEAT, BRAKE RETURN SPPING (FOR REAR BRAKE)

main35627-22010iRA43..CP..5F..GT;MA46,RA42..(3FC,5F)..(LT,SPR)197708-198107

35627SRING, SHAFT SNAP (FOR REAR BRAKE RETURN SPRING SEAT)

main90520-52262iRA43..CP..5F..GT;MA46,RA42..(3FC,5F)..(LT,SPR)197708-198107

35662HUB, BRAKE

main35662-22011iMA46,RA42..(3FC,5F)..(LT,SPR)197708-198008

main35662-30010iRA43..CP..5F..GT198008-198107

35709SUPPORT SUB-ASSY, CENTER

main35709-22011iMA46,RA42..(3FC,5F)..(LT,SPR)197708-198008

main35709-22040iRA43..CP..5F..GT;MA46,RA42..(3FC,5F)..(LT,SPR)197904-198107

main35709-30030iMA46,RA42..(3FC,5F)..(LT,SPR)197901-197904

main35709-30040iRA43..CP..5F..GT198008-198107

35709CRING, OIL SEAL (FOR CENTER SUPPORT)

main35617-22020×3iRA43..CP..5F..GT;MA46,RA42..(3FC,5F)..(LT,SPR)197708-198107

35790CLUTCH ASSY, 1 WAY

main35791-22010iMA46,RA42..(3FC,5F)..(LT,SPR)197708-198008

main35791-30020iRA43..CP..5F..GT198008-198107

35793RETAINER, 1 WAY CLUTCH

main35793-22011×2iRA43..CP..5F..GT;MA46,RA42..(3FC,5F)..(LT,SPR)197708-198107

9010908073

main90109-08073

9454200800

main94542-00800

28 parts on this diagram · 2 diagrams in section
