DISC WHEEL & WHEEL CAP

42601WHEEL, DISC

main42611-47440×4i201905-202012

15X6.5J, #,TYPE B:REFER ILLUST.

main42611-47441×4i202012

15X6.5J, #,TYPE B:REFER ILLUST.

main42611-47450×4i201905

15X6.5J, #,TYPE A:REFER ILLUST.

main42611-47600×4i202007

15X6.5J, #,CANADA SPEC&TIRE & DISC WHEEL-195/65R15 CANADA 6.5J ALUMINUM,TYPE C:REFER ILLUST.

42601CNUT, HUB (FOR AXLE)

main90942-01033×20i201609-201904

42603ORNAMENT SUB-ASSY, WHEEL HUB

main42603-52170×4i202007

*ALU,TIRE & DISC WHEEL-195/65R15 CANADA 6.5J ALUMINUM,TYPE A:REFER ILLUST.

3 parts on this diagram · 2 diagrams in section
