DISC WHEEL & WHEEL CAP

0001 1 0002 1

42601WHEEL, DISC

main42611-47030×4iNHW11200005

14X5.5JJ,TYPE A:REFER TO ILLUSTRATION

42601AWHEEL, DISC (FOR SPARE)

main42611-10321iNHW11200005

16X4T,TYPE B:REFER TO ILLUSTRATION

42601CNUT, HUB (FOR AXLE)

main90942-01033×16iNHW11200005

42603ORNAMENT SUB-ASSY, WHEEL HUB

main42603-20620×4iNHW11200005

*ALU,TYPE A:REFER TO ILLUSTRATION

42611GVALVE (FOR TUBELESS TIRE)

main90942-05009×4iNHW11200005

42611JVALVE (FOR TUBELESS TIRE SPARE)

main90942-05009iNHW11200005

42652TIRE

main42652-47030×4iNHW11200005-200112

175/65R14 84S

main42652-47060×4iNHW11..CND200112

175/65R14 84S

42652ATIRE (FOR SPARE)

main42652-2B440iNHW11200005

T125/70D16,*B/S

8 parts on this diagram · 2 diagrams in section
