OIL COOLER & TUBE (ATM)

32921TUBE, OIL COOLER INLET, NO.1

main32921-12190iAE86..4FC198308-198505

main32921-12340iAE86..4FC198505-198707

32921ANUT, UNION(FOR OIL COOLER TUBE)

main90402-13041×2iAE86..4FC198308-198707

32921BOLIVE(FOR OIL COOLER TUBE)

main96395-71400×2iAE86..4FC198308-198707

32921CUNION(FOR OIL COOLER TUBE)

main90404-13003iAE86..4FC198308-198707

INNLET

main90407-13005iAE86..4FC198308-198707

OUTLET

32921DHOSE(FOR OIL COOLER INLET)

main32941-12080iAE86..4FC198308-198707

32921ECLAMP, HOSE(FOR OIL COOLER)

main90460-14085×4iAE86..4FC198308-198707

32921GRING, O(FOR OIL COOLER TUBE UNION)

main90301-10189×2iAE86..4FC198308-198707

32922TUBE, OIL COOLER OUTLET, NO.1

main32922-12180iAE86..4FC198308-198505

main32922-12270iAE86..4FC198505-198707

32922AHOSE(FOR OIL COOLER OUTLET)

main32942-12090iAE86..4FC198308-198707

32926CUSHION, OIL COOLER TUBE(ATM)

main32926-30011×2iAE86..4FC198308-198707

L=25,ID=8

9161140614

main91611-40614

11 parts on this diagram · 1 diagram in section
