THROTTLE LINK & VALVE LEVER (ATM)

0001 1A131L 0002 1A240L 0003 1A131L,A240L 0004 1A131L,A240L

35501ROD SUB-ASSY, PARKING LOCK

main35501-12010iAE92..4FC198708-198908

main35501-32010iAE92..3FC198708-198808

main35501-32030iAE92..3FC198808-199106

35505LEVER SUB-ASSY, MANUAL VALVE

main35505-12020iAE92..4FC198708-198801

main35505-12030iAE92..4FC198801-198811

main35505-20010iAE92..3FC198712-198808

main35505-20040iAE92..4FC198811-198908

main35505-32011iAE92..3FC198708-198712

main35505-32030iAE92..3FC198808-199106

35505BSPACER (FOR MANUAL VALVE LEVER)

main90560-20006iAE92..ATM198708-199106

35505GPIN, SLOTTED SPRING (FOR MANUAL VALVE LEVER)

main90254-04011iAE92..ATM198708-199106

35506FSEAL, OIL (FOR MANUAL VALVE LEVER SHAFT)

main90311-12002iAE92..ATM198708-199106

35506JSPRING, RETAINER (FOR MANUAL VALVE LEVER SHAFT)

main90524-09001iAE92..3FC198708-199106

main90524-11001iAE92..4FC198708-199106

35556SHAFT, PARKING LOCK PAWL

main35556-12020iAE92..4FC198708-199106

main35556-32010iAE92..3FC198708-199106

35557PAWL, PARKING LOCK

main35557-12020iAE92..4FC198708-199106

main35557-32020iAE92..3FC198708-199106

35557ASPRING, TORSION (FOR PARKING LOCK PAWL)

main90508-21003iAE92..4FC198708-199106

main90508-26047iAE92..3FC198708-199106

35561SHAFT, MANUAL VALVE LEVER

main35561-12020iAE92..4FC198708-199106

main35561-32010iAE92..3FC198708-199106

35572ALEVER, TRANSMISSION CONTROL SHAFT

main35572-12080iAE92..4FC198708-199106

main35572-12090iAE92..3FC198708-199106

35595BRACKET, PARKING LOCK PAWL

main35595-32010iAE92..3FC198708-199106

9161160614

main91611-60614

9411050800

main94110-50800

9451200800

main94512-00800

15 parts on this diagram · 4 diagrams in section
