THROTTLE LINK & VALVE LEVER (ATM)

0001 1 0002 1 0003 1

35505LEVER SUB-ASSY, MANUAL VALVE

main35505-12020iAE82..4FC198408-198707

main35505-32011iAE82,CE80..3FC198308-198707

35506SHAFT SUB-ASSY, MANUAL VALVE LEVER

main35561-12020iAE82..4FC198408-198707

main35561-32010iAE82,CE80..3FC198308-198707

35506CPIN, SLOTTED SPRING (FOR MANUAL VALVE LEVER SHAFT)

main90254-04011iAE82,CE80..ATM198308-198707

35506FSEAL, OIL (FOR MANUAL VALVE LEVER SHAFT)

main90311-12002iAE82,CE80..ATM198308-198707

35506HSPACER (FOR MANUAL VALVE LEVER SHAFT)

main90560-20006iAE82,CE80..ATM198308-198707

35506JSPRING, RETAINER (FOR MANUAL VALVE LEVER SHAFT)

main90524-09001iAE82,CE80..3FC198308-198707

main90524-11001iAE82..4FC198408-198707

35556SHAFT, PARKING LOCK PAWL

main35556-12020iAE82..4FC198408-198707

main35556-32010iAE82,CE80..3FC198308-198707

35557PAWL, PARKING LOCK

main35557-12020iAE82..4FC198408-198707

main35557-32010iAE82,CE80..3FC198308-198404

main35557-32020iAE82,CE80..3FC198404-198707

35557ASPRING, TORSION (FOR PARKING LOCK PAWL)

main90508-21003iAE82..4FC198412-198707

main90508-26047iAE82,CE80..3FC198308-198707

main90508-26058iAE82..4FC198408-198412

35585ROD, PARKING LOCK

main35501-12010iAE82..4FC198408-198707

main35501-32010iAE82,CE80..3FC198308-198707

35595BRACKET, PARKING LOCK PAWL

main35595-32010iAE82,CE80..3FC198308-198707

9161160614

main91611-60614

9411050800

main94110-50800

9451200800

main94512-00800

14 parts on this diagram · 3 diagrams in section
