DISC WHEEL & WHEEL CAP

42601WHEEL, DISC

main42611-10180×4iKP61198008-198312

4.5J-13,TYPE A

main42611-12490iKP61198008-198312

4T-14,TYPE B,SPARE TIRE

42601CNUT, HUB (FOR AXLE)

main90942-01027×16iKP61198008-198312

42601DWEIGHT, BALANCE (FOR DISC WHEEL)

main90942-03017iKP61198008-198312

20G,T=8,20G

main90942-03020iKP61198008-198312

30G,T=10,30G

main90942-03022iKP61198008-198312

40G,T=9.5,40G

main90942-03025iKP61198008-198312

50G,T=9.5,50G

main90942-03027iKP61198008-198312

60G,T=9.5,60G

main90942-03029iKP61198008-198312

70G,T=9.5,70G

main90942-03031iKP61198008-198312

80G,T=9.5,80G

main90942-03041iKP61198008-198312

10G,T=7.5,10G

main90942-03098iKP61198008-198312

15G,15G

main90942-03099iKP61198008-198312

25G,25G

main90942-03100iKP61198008-198312

35G,35G

main90942-03101iKP61198008-198312

45G,45G

main90942-03102iKP61198008-198312

55G,55G

main90942-03108iKP61198008-198312

65G,65G

main90942-03109iKP61198008-198312

75G,75G

42603ORNAMENT SUB-ASSY, WHEEL HUB

main42603-10080×4iKP61198008-198312

42611ATIRE TUBE SET OR TUBELESS TIRE

main42652-10080×4iKP61198008-198108

145SR13

main42652-12370iKP61198008-198312

T115/70 D14,SPARE TIRE

main42652-16080×4iKP61198108-198312

145SR13

42611GVALVE (FOR TUBELESS TIRE)

main90942-05009×5iKP61198008-198312

6 parts on this diagram · 1 diagram in section
