DISC WHEEL & WHEEL CAP

0001 1 0002 1

42601WHEEL, DISC

main42611-52310×4iNCP61200304-200507

15X5.5JJ, #,TYPE B:REFER ILLUST.

42601AWHEEL, DISC (FOR SPARE)

main42611-52400iNCP61200304-200507

16X4T,TYPE D:REFER ILLUST.

42601CNUT, HUB (FOR AXLE)

main90942-01007×16iNCP61200304-200507

TYPE A:REFER ILLUST.

42611GVALVE (FOR TUBELESS TIRE)

main90942-05009×4iNCP61200304-200507

42611JVALVE (FOR TUBELESS TIRE SPARE)

main90942-05009iNCP61200304-200507

42652TIRE

main42652-52300×4iNCP61200304-200507

185/60R15,*D/L

main42652-52870×4iNCP61200510-200612

185/60R15 *B/S

42652ATIRE (FOR SPARE)

main42652-13120iNCP61200510-200612

T125/70D16,*D/L

7 parts on this diagram · 2 diagrams in section
