HEATING & AIR CONDITIONING - COOLER PIPING

0001 1������ & ������ 0002 1�������

88453AFAN, COOLING

main88453-37030iXKC605,XKU605,645,655202103

88454ASHROUD, FAN

main88454-37180iXKC605,XKU605,645,655202103

88460BBRACKET, COOLER CONDENSER, NO.1

main85924-37010iXKC605,XKU605,645,655202103

88460CBRACKET, COOLER CONDENSER, NO.2

main85924-37030iXKC605,XKU605,645,655202103

88461ACORE, COOLER CONDENSER

main88461-37270iXKC605,XKU605,645,655202103

88461BCOVER, COOLER CONDENSER

main53716-37310iXKC605,XKU605,645,655202103

88474DRYER, COOLER

main88474-12010iXKC605,XKU605,645,655202103

88550MOTOR ASSY, BLOWER (FOR CONDENSER)

main88550-37140iXKC605,XKU605,645,655202103

88892CPLATE, CONDENSER, NO.1

main58229-37071iXKC605,XKU605,645,655202103

8884937060BRACKET, COOLER COMPRESSOR, NO.2

main88849-37060

8884937070BRACKET, COOLER COMPRESSOR, NO.2

main88849-37070

8884937080BRACKET, COOLER COMPRESSOR, NO.2

main88849-37080

8884937090BRACKET, COOLER COMPRESSOR, NO.2

main88849-37090

9009120619

main90091-20619

9009120641

main90091-20641

9009904119

main90099-04119

9009905164

main90099-05164

9011910522

main90119-10522

9017908132

main90179-08132

9155180814

main91551-80814

9155180825

main91551-80825

9415180800

main94151-80800

22 parts on this diagram · 2 diagrams in section
