SWITCH & RELAY & COMPUTER

0001 1����� 1/2 0002 1����� 2/2 0003 1����� 2/2 0004 1����� 0005 1��������� 0006 1��������� 0007 1�������� 0008 1�������� 0009 1��� 0010 1��� 1/2 0011 1��� 2/2 0012 1������������ 0013 1������������ 0014 1������� 0015 1������� 0016 1���,��� & ��� 0017 1���,��� & ��� 0018 1������� 0019 1�������

83420GAGE ASSY, WATER TEMPERATURE SENDER

mainS834201250iXKU640,655;XKU605..IV3;XKU605..T4..CBU;XKU600..T5..30T..CBU;XKU600,650..(T3,T5)..IV3;XKC605,645,655,XKU600,645,650..DM6,T4201107-201705

83530SWITCH ASSY, OIL PRESSURE (FOR ENGINE)

main83530-E0220iXKU640,655;XKU605..IV3;XKU605..T4..CBU;XKU600..T5..30T..CBU;XKU600,650..(T3,T5)..IV3;XKC605,645,655,XKU600,645,650..DM6,T4201107-201705

main83530-E0250iXKC605,XKU605,645,655201909

89420MSENSOR ASSY, AIR PRESSURE

main89421-E0050iXKC655..T3;XKU650..T3..CBU;XKU60#..T5..20T..CBU201107-201505

89424BSWITCH, INLET AIR TEMPERATURE

main89424-37020iXKC655..T3;XKU650..T3..CBU;XKU60#..T5..20T..CBU201107-201505

89425SENSOR, EXHAUST GAS TEMPERATURE

main89425-37300iXKC655..T3;XKU650..T3..CBU;XKU60#..T5..20T..CBU201107-201505

89425ASENSOR, EXHAUST GAS TEMPERATURE, NO.2

main89425-37080iXKC655..T3;XKU650..T3..CBU;XKU60#..T5..20T..CBU201107-201505

main89425-37350×5iXKC605,XKU605,645,655201905

89425BSENSOR, EXHAUST GAS TEMPERATURE, NO.3

main89425-37200iXKC655..T3;XKU650..T3..CBU;XKU60#..T5..20T..CBU201107-201505

89425CSENSOR, EXHAUST GAS TEMPERATURE, NO.4

main89425-37240iXKC655..T3;XKU650..T3..CBU;XKU60#..T5..20T..CBU201107-201505

89458DSENSOR, FUEL PRESSURE

main89458-E0030iXKC655..T3;XKU650..T3..CBU;XKU60#..T5..20T..CBU201107-201505

main89458-E0050iXKC605,XKU605,645,655201905

89480ASENSOR ASSY, DIFFERENTIAL PRESSURE

main89480-37010iXKC655..T3;XKU650..T3..CBU;XKU60#..T5..20T..CBU201107-201505

9415180800

main94151-80800

SH51110614

mainSH511-10614

SL72201010

mainSL722-01010

SZ43010005WASHER, SOFT, NO.1

mainSZ430-10005

SZ43014002WASHER, SOFT, NO.1

mainSZ430-14002

15 parts on this diagram · 19 diagrams in section
