CAUTION PLATE & NAME PLATE (ENGINE)

11283PLATE, TURBOCHARGER CAUTION

11289PLATE, SPARK PLUG CAUTION

main11289-72010i3YP..YU60,80198409-198606

main11289-73010i3YP..YU60,80198606-198708

11291PLATE, ENGINE NAME

main11291-73010i3Y..YU6#,70198409-198708

3Y

main11291-73030i3YP..YU60,80198409-198708

3YP

11293PLATE, ENGINE CAUTION & ENGINE NAME

main11293-73040i3YP..YU60,80198409-198508

main11293-78010i1W..WU75,9#198409-198708

11294PLATE, ENGINE CAUTION, NO.2

main11294-56010i1W..WU75,9#198409-198708

COLD SPEC

11297PLATE, ENGINE CAUTION, NO.3

main11297-71010i3Y..YU6#,70198409-198708

11299PLATE, IDLE ADJUSTING CAUTION

main11299-73040i3Y..YU60,70198409-198508

17700CPLATE, AIR CLEANER CAUTION (FOR ENGINE MODEL)

main17791-64020i1W,3Y#..WU75,9#,YU6#,70,80198409-198708

17792PLATE, ENGINE VACUUM HOSE INFORMATION

main17792-73090i3YP..YU60,80198409-198508

main17792-73091i3YP..YU60,80198508-198708

main17792-73100i3Y..YU60,70198409-198508

main17792-73101i3Y..YU6#,70198508-198708

9 parts on this diagram · 1 diagram in section
