REAR DISC BRAKE CALIPER & DUST COVER

0001 1 0002 1 0003 1

04466PAD KIT, DISC BRAKE, REAR

main04465-37220iXZC605,645,655202103

main04465-37230iXZU650,652..(35T,40T)..(CBU,IV3)202103

main04466-37141iXZU600..T3..(IV3,IV4,IV7);XZU605,640,645,650,655..(20T,30T)..(CBU,IV3,IV4,IV6)202103

04479ACYLINDER KIT, DISC BRAKE, REAR

main0447B-37010×2iXZC605,645,655202103

main0447B-37030×2iXZU650,652..(35T,40T)..(CBU,IV3)202103

main0447C-37010×2iXZU600..T3..(IV3,IV4,IV7);XZU605,640,645,650,655..(20T,30T)..(CBU,IV3,IV4,IV6)202103

04946SHIM KIT, ANTI SQUEAL(FOR REAR DISC BRAKE)

main04945-37051iXZU650,652..(35T,40T)..(CBU,IV3)202103

main04945-37240iXZC605,645,655202103

main04946-37031iXZU600..T3..(IV3,IV4,IV7);XZU605,640,645,650,655..(20T,30T)..(CBU,IV3,IV4,IV6)202103

04948FITTING KIT, DISC BRAKE, REAR

main0494A-37010×2iXZC605,645,655202103

main0494A-37030×2iXZU600,650,652..(T3,T4)..(CBU,IV3,IV4,IV7);XZU605,640,645,655..(20T,30T)..(CBU,IV3,IV4,IV6)202103

31478CCAP, BLEEDER PLUG(FOR REAR DISC BRAKE)

main31478-30010×2iXZC605,645,655202103

main31478-37030×2iXZU600,650,652..(T3,T4)..(CBU,IV3,IV4,IV7);XZU605,640,645,655..(20T,30T)..(CBU,IV3,IV4,IV6)202103

47547CPLUG, BLEEDER(FOR REAR DISC BRAKE)

main47547-12030×2iXZC605,645,655202103

main47847-37030×2iXZU600,650,652..(T3,T4)..(CBU,IV3,IV4,IV7);XZU605,640,645,655..(20T,30T)..(CBU,IV3,IV4,IV6)202103

47715CPIN, CYLINDER SLIDE(FOR REAR DISC BRAKE)

main47715-37260×4iXZC605,645,655202103

47721DBOLT(FOR REAR DISC BRAKE CYLINDER MOUTING)

main90015-AA601×4iXZC605,645,655202103

main90105-37120×4iXZU600,650,652..(T3,T4)..(CBU,IV3,IV4,IV7);XZU605,640,645,655..(20T,30T)..(CBU,IV3,IV4,IV6)202103

47731BPISTON, REAR DISC BRAKE

main47731-37120×4iXZU650,652..(35T,40T)..(CBU,IV3)202103

main47731-60070×4iXZC605,645,655202103

47803COVER SUB-ASSY, DISC BRAKE DUST, REAR RH

main47803-37011iXZU650,652..(35T,40T)..(CBU,IV3)202103

main47803-37040iXZU600..T3..(IV3,IV4,IV7);XZC605,645,655,XZU605,640,645,650,655..(20T,30T)..(CBU,IV3,IV4,IV6)202103

47804COVER SUB-ASSY, DISC BRAKE DUST, REAR LH

main47804-37011iXZU650,652..(35T,40T)..(CBU,IV3)202103

main47804-37040iXZU600..T3..(IV3,IV4,IV7);XZC605,645,655,XZU605,640,645,650,655..(20T,30T)..(CBU,IV3,IV4,IV6)202103

47821MOUNTING, REAR DISC BRAKE CYLINDER, RH

main47821-37010iXZU650,652..(35T,40T)..(CBU,IV3)202103

main47821-37030iXZU600..T3..(IV3,IV4,IV7);XZU605,640,645,650,655..(20T,30T)..(CBU,IV3,IV4,IV6)202103

main47821-37040iXZC605,645,655202103

47822MOUNTING, REAR DISC BRAKE CYLINDER, LH

main47821-37010iXZU650,652..(35T,40T)..(CBU,IV3)202103

main47822-37030iXZU600..T3..(IV3,IV4,IV7);XZU605,640,645,650,655..(20T,30T)..(CBU,IV3,IV4,IV6)202103

main47822-37040iXZC605,645,655202103

47830CYLINDER ASSY, DISC BRAKE, REAR RH

main47830-37012iXZU650,652..(35T,40T)..(CBU,IV3)202103

main47830-37031iXZU600..T3..(IV3,IV4,IV7);XZU605,640,645,650,655..(20T,30T)..(CBU,IV3,IV4,IV6)202103

main47830-37042iXZC605,645,655202103

47850CYLINDER ASSY, DISC BRAKE, REAR LH

main47850-37012iXZU650,652..(35T,40T)..(CBU,IV3)202103

main47850-37031iXZU600..T3..(IV3,IV4,IV7);XZU605,640,645,650,655..(20T,30T)..(CBU,IV3,IV4,IV6)202103

main47850-37042iXZC605,645,655202103

9010514179

main90105-14179

91611B0812

main91611-B0812

17 parts on this diagram · 3 diagrams in section
