RADIATOR SUPPORT & WIND GUIDE

53167ROD, RADIATOR BRACE, RH

main53016-36020iBU2#,30,31,32,33,34197904-198408

main53016-36030iBU35,36,37,40,41,45,5#198008-198408

main53167-36020iBU2#,30197708-197904

53168ROD, RADIATOR BRACE, LH

main53018-36020iBU35,36,37,40,41,45,5#198008-198408

main53169-36020iBU2#,30,31,32,33,34197708-198408

53173SHUTTER SUB-ASSY, RADIATOR WIND

main87540-95407iBU20,30198102-198204

COLD SPEC

main87540-95408iBU35,36,37,4#,5#198107-198408

COLD SPEC

main87540-95409iBU2#,30,32,33,34198204-198408

COLD SPEC

53173ASTOPPER, RADIATOR SHUTTER WIRE

main87542-95404iBU2#,3#197708-198008

COLD SPEC

53174APACKING, NO.1(FOR RADIATOR WIND SHUTTER)

main53724-95402iBU2#,33,34198302-198408

W/COOLER

main88899-95400iBU2#,3#197906-198008

W/COOLER

main88899-95404iBU2#,30,32198008-198302

W/COOLER

53174BPACKING, NO.2(FOR RADIATOR WIND SHUTTER)

main88899-95401iBU2#,30,31,32197906-198302

W/COOLER

53174CPACKING, NO.3(FOR RADIATOR WIND SHUTTER)

main53726-95400iBU2#,33,34198302-198408

W/COOLER

main88899-95402iBU2#,30,31,32197906-198302

W/COOLER

53174DPACKING, NO.4(FOR RADIATOR WIND SHUTTER)

main53727-95400iBU2#,33,34198302-198408

W/COOLER

main88899-95403iBU2#,30,31,32197906-198302

W/COOLER

sub88893-28010

53188BRACKET, RADIATOR BRACE ROD, RH

main53221-36010iBU2#,3#,4#,5#197708-198408

53211SUPPORT, RADIATOR, RH

main53211-36020iBU2#,3#,4#,5#197708-198408

53211ABRACKET, RADIATOR SUPPORT, RH

main51411-36030iBU2#,30,31,32,33,34197708-198408

main51411-36040iBU35,36,37,4#,5#198008-198408

53212SUPPORT, RADIATOR, LH

main53212-36020iBU2#,3#,4#,5#197708-198408

53212ABRACKET, RADIATOR SUPPORT, LH

main51412-36040iBU2#,30,31,32,33,34197708-198408

main51412-36050iBU35,36,37,4#,5#198008-198408

53241AGUIDE, SIDE WIND, RH

main16593-56010iBU35,36,37,41,46,51198008-198408

main53241-36020iBU20,30197708-197801

main53241-36021iBU20,22,23,25,30,31,33,34197801-198408

53242BGUIDE, SIDE WIND, LH

main16595-56010iBU35,36,37,41,46,51198008-198408

main53242-36020iBU20,30197708-197801

main53242-36021iBU20,22,23,25,30,31,33,34197801-198408

53243BGUIDE, LOWER WIND

main53204-36010iBU2#,30,31197708-198112

COLD SPEC

main53240-36020iBU2#,30197708-198112

main53240-36030iBU31197904-198008

main53240-36050iBU36,37,4#,5#198204-198408

COLD SPEC

main53240-36060iBU2#,30,32,33,34198112-198408

COLD SPEC

main53240-36070iBU20,22,30,33198204-198408

main53240-36080iBU21,23,32,34198204-198408

main53243-36030iBU35,36,37,4#,5#198008-198408

main53243-36040iBU20,30198112-198204

53243CSHIELD, RADIATOR TO LOWER WIND GUIDE

main53292-36030iBU35,36,37,4#,5#198008-198408

53291ASHIELD, RADIATOR TO CAB FLOOR PANEL

main16594-56010iBU35,36,37,41,46,51198008-198408

main16594-58020iBU2#,33,34198302-198408

main53291-36010iBU20,25,30,31197708-198302

9015940094

main90159-40094

9017908001

main90179-08001

9017908024

main90179-08024

9044011043

main90440-11043

9048008002

main90480-08002

9048017254

main90480-17254

9054010003

main90540-10003

9054010022

main90540-10022

9161140816

main91611-40816

9161140820

main91611-40820

9165140814

main91651-40814

9165640820

main91656-40820

9165640825

main91656-40825

9166140816

main91661-40816

9166140828

main91661-40828

9166140840

main91661-40840

9322915012

main93229-15012

9338215014

main93382-15014

9356014010

main93560-14010

9411040800

main94110-40800

9451200800

main94512-00800

39 parts on this diagram · 1 diagram in section
