ELECTRONIC DIESEL INJECTION CONTROL SYSTEM

28571MOTOR, FUEL CONTROL

main28571-56060i2J..JY30197903-198004

12V

main28571-56070i2J..JY30197903-198004

24V

main28571-56130iB..BY30198009-198308

24V

main28571-56170i2J..JY30198004-198308

12V

main28571-56180i2J..JY30198004-198308

24V

28571AROD, FUEL CONTROL MOTOR

main84580-36021iB..BY30198009-198308

main84580-36031i2J..JY30197903-198308

28578COVER, FUEL CONTROL MOTOR

main28578-56010iB..BY30198009-198308

28579BRACKET, FUEL CONTROL MOTOR

main28579-56030iB..BY30198009-198308

main28579-56040i2J..JY30197903-198308

28590RELAY ASSY, FUEL CONTROL

main28590-25010i2J..JY30198201-198308

12V

main28590-25020iB,2J..BY30,JY30198201-198308

24V

main28590-56021i2J..JY30197903-198004

12V

main28590-56031i2J..JY30197903-198004

24V

main28590-56090i2J..JY30198004-198201

12V

main28590-56100i2J..JY30198004-198201

24V

9011906111

main90119-06111

9046108187

main90461-08187

9046108265

main90461-08265

9161160665

main91611-60665

9165140612

main91651-40612

9165140616

main91651-40616

9165160825

main91651-60825

9461111200

main94611-11200

13 parts on this diagram · 1 diagram in section
