DISC WHEEL & WHEEL CAP

42601CNUT, HUB (FOR AXLE)

main90942-01004×6iLH24,RH24..WT198211-198507

RH,RR

main90942-01007×20iLH24,RH24198211-198507

main90942-01009×6iLH24,RH24..WT198211-198507

LH,RR

main90942-01027×20iLH24,RH24198211-198507

185R14 TIRE

42601DWEIGHT, BALANCE (FOR DISC WHEEL)

main90942-03017iLH24,RH24198211-198507

main90942-03020iLH24,RH24198211-198507

main90942-03022iLH24,RH24198211-198507

main90942-03025iLH24,RH24198211-198507

main90942-03027iLH24,RH24198211-198507

main90942-03029iLH24,RH24198211-198507

main90942-03031iLH24,RH24198211-198507

main90942-03041iLH24,RH24198211-198507

42601FWHEEL, DISC (FOR FRONT)

main42601-26170×3iLH24,RH24198211-198507

4.5J-14,TYPE A

main42601-26180×3iLH24,RH24198211-198507

42601RWHEEL, DISC (FOR REAR)

main42601-25081×5iLH24,RH24..WT198211-198507

4J-12,TYPE B

main42601-26170×3iLH24,RH24..ST198211-198507

4.5J-14,TYPE A

main42601-26180×3iLH24,RH24..ST198211-198507

42603ORNAMENT SUB-ASSY, WHEEL HUB

main42603-26030×4iLH24,RH24198211-198507

42611ATIRE TUBE SET OR TUBELESS TIRE

main42605-26090×2iLH24,RH24..T3198309-198507

175R14-6,SINGLE TIRE JUSTLOW

main42605-26120×5iLH24,RH24..WT198211-198507

155R12-6,RR,W/TUBE

main42605-26140×3iLH24,RH24198211-198507

6.00-14-6,FR,W/TUBE

main42605-26150×3iLH24,RH24..ST198211-198507

6.00-14-8,RR,W/TUBE

main42605-26170×3iLH24,RH24198211-198507

185R14-6,FR,W/TUBE

main42605-26180×3iLH24,RH24..ST198211-198507

185R14-8,RR,W/TUBE

main42605-36190×3iLH24,RH24..T3198309-198507

175R14-8,SINGLE TIRE JUSTLOW

main98051-50123×5iLH24,RH24..WT198211-198507

5.00-12-6,RR,W/TUBE,*(Y),*(T)

main98058-50123×5iLH24,RH24..WT198211-198507

5.00-12-6,RR,W/TUBE,*(B),*(D)

6 parts on this diagram · 1 diagram in section
