DISC WHEEL & WHEEL CAP

Parts diagram

42601WHEEL, DISC

main42611-97523×4i200009-200206

main42611-97524×4i200009-200206

main42611-97538×4i200206

main42611-97539×4i200206

42601AWHEEL, DISC (FOR SPARE)

main42611-97522i200009-200206

main42611-97540i200206

42601CNUT, HUB (FOR AXLE)

main90049-11036×16i200009

main90049-11037×16i200206

main90049-11058×16i200010-200206

42601DWEIGHT, BALANCE (FOR DISC WHEEL)

main90049-14037×33i200009

main90049-14038×33i200009

main90049-14043×33i200009

main90049-14044×33i200009

main90049-14072×33i200009

main90049-14073×33i200009

main90049-14074×33i200009

main90049-14075×33i200009

main90049-14076×33i200009

main90049-14077×33i200009

main90049-14078×33i200009

main90049-14079×33i200009

main90049-14080×33i200009

main90049-14118×33i200009

main90049-14119×33i200009

main90049-14120×33i200009

main90049-14121×33i200009

main90049-14146×33i200009

main90049-14147×33i200009

main90049-14148×33i200009

main90049-14149×33i200009

main90049-14150×33i200009

main90049-14151×33i200009

main90049-14152×33i200009

main90049-14159×33i200009

main90049-14161×33i200009

main90049-14163×33i200009

main90049-14165×33i200009

main90049-14167×33i200009

main90049-14169×33i200009

main90049-14171×33i200009

42603ORNAMENT SUB-ASSY, WHEEL HUB

main42638-97205×4i200009

42611GVALVE (FOR TUBELESS TIRE)

main90049-02019×4i200009

42621CAP, WHEEL

main42602-97505×4i200009

7 parts on this diagram · 2 diagrams in section
