Toyota PIXIS MEGA — REAR AXLE SHAFT & HUB
4103DISC WHEEL & WHEEL CAP
42311UBOLT, HUB(FOR REAR AXLE RH)
42312SHAFT, REAR AXLE, LH
42312EBOLT, HUB(FOR REAR AXLE LH)
42409CBOLT (FOR REAR AXLE BEARING RH)
42409DBOLT (FOR REAR AXLE BEARING LH)
4706REAR DRUM BRAKE WHEEL CYLINDER & BACKING PLATE
8414ABS & VSC
11 parts on this diagram · 2 diagrams in section
REAR AXLE SHAFT & HUB for Toyota PIXIS MEGA
This section contains 22 genuine Toyota parts for the REAR AXLE SHAFT & HUB system of the Toyota PIXIS MEGA. Key components include: DISC WHEEL & WHEEL CAP, SHAFT, REAR AXLE, RH, BOLT, HUB(FOR REAR AXLE RH), SEAL, OIL(FOR REAR AXLE SHAFT RH), BEARING(FOR REAR AXLE SHAFT INNER RH).
