FUEL INJECTION SYSTEM

0001 1 0002 1

1701MANIFOLD

→ Go to FIG 17-01

1708VACUUM PIPING

→ Go to FIG 17-08

21553AGUIDE, FUEL MAIN

main21553-B2010iKFV#..LA700,710201605

22030BODY ASSY, THROTTLE W/THROTTLE POSITION SENSOR

main22030-B2020iKFV#..LA700,710201605

main22030-B2040iKFV#..LA700,710201605

22267BRACKET, THROTTLE BODY

main58239-B2030iKFV#..LA700,710201507-201605

23250INJECTOR ASSY, FUEL

main23250-B2020×3iKFVET..LA700,710201605

main23250-B2050×3iKFVE..LA700,710201605

23250BRING, O(FOR FUEL INJECTOR)

main90043-01349×3iKFV#..LA700,710201605

23250GRING, O, NO.2(FOR FUEL INJECTOR)

main90043-01348×3iKFV#..LA700,710201507-201605

23270DAMPER ASSY, FUEL PRESSURE PULSATION

main23270-B2010iKFV#..LA700,710201507-201605

23271FHOSE, FUEL

main77260-B2020iKFV#..LA700,710201507-201605

main77260-B2060iKFV#..LA700,710201605

23273DCLIP(FOR FUEL HOSE NO.2)

main90044-67400iKFV#..LA700,710201605

23295HOLDER, INJECTOR, NO.1

main23295-B2020×3iKFV#..LA700,710201507-201605

23807PIPE SUB-ASSY, FUEL DELIVERY

main23807-B2020iKFV#..LA700,710201605

23807PCLIP(FOR FUEL HOSE)

main90044-67400iKFV#..LA700,710201605

23807SRING, O(FOR FUEL DELIVARY PIPE)

main90043-01353iKFV#..LA700,710201605

7701FUEL TANK & TUBE

→ Go to FIG 77-01

9004116497

main90041-16497

9004120214

main90041-20214

9167180616

main91671-80616

9167180645

main91671-80645

9415180600

main94151-80600

21 parts on this diagram · 2 diagrams in section
