REAR SEAT & SEAT TRACK

0001 1��NO.1���(RH) 0002 1��NO.1���(LH) 0003 1��NO.2��� 0004 1�������

64928AHOLDER, TONNEAU COVER HOOK

main64928-48010-C0×3iMHU28200503-200705

BLACK,TRIM2#

71015AFRAME SUB-ASSY, REAR SEAT CUSHION, RH

main71650-48060iMHU28200503

71017FRAME SUB-ASSY, REAR SEATBACK, RH

main71017-48120iMHU28200503

7104SEAT BELT & CHILD RESTRAINT SEAT

→ Go to FIG 71-04

71047SFRAME SUB-ASSY, REAR SEATBACK, LOWER RH

main71047-48030iMHU28200503

71075SCOVER, REAR SEAT CUSHION, RH (FOR SEPARATE TYPE)

main71075-48280-C5iMHU28200503-200705

BLACK,TRIM2#

71077SCOVER, REAR SEATBACK, RH (FOR SEPARATE TYPE)

main71077-48430-C1iMHU28200503-200705

BLACK,TRIM2#

71305SFRAME SUB-ASSY, CENTER SEATBACK

main71305-48040iMHU28200503

71350TBACK ASSY, CENTER SEAT

main71350-48060-C0iMHU28200503-200705

BLACK,TRIM2#

71398HCOVER, CENTER SEAT HINGE, UPPER LH

main71398-48010-C0iMHU28200503-200705

BLACK,TRIM2#

71611APAD, REAR SEAT CUSHION, RH

main71611-48250iMHU28200503

71651SPAD, REAR SEATBACK, RH(FOR SEPARATE TYPE)

main71651-48160iMHU28200503

71825BMOULDING, REAR SEAT CUSHION, RH

main71825-48040-C0iMHU28200503-200705

BLACK,TRIM2#

71828BMOULDING, REAR SEAT CUSHION, REAR RH

main71828-48050-C0iMHU28200503-200705

BLACK,TRIM2#

71835CMOULDING, REAR SEATBACK, RH

main71835-48010-C0iMHU28200503-200705

BLACK,TRIM2#

71836CMOULDING, REAR SEATBACK, LH

main71836-48010-C0iMHU28200503-200705

BLACK,TRIM2#

71875CCOVER, RECLINING ADJUSTER INSIDE, RH

main71875-48070-C0iMHU28200503-200705

BLACK,TRIM2#

71878ACOVER, REAR SEAT RECLINING, INNER RH

main71878-48020-C0iMHU28200503-200705

BLACK,TRIM2#

71880ACARPET ASSY, REAR SEATBACK BOARD, RH

main71880-48180-C0iMHU28200503-200705

BLACK,TRIM2#

71931ASUPPORT, REAR SEAT HEADREST

main71930-42020-C0×2iMHU28200503-200705

main71931-42020-C0×2iMHU28200503-200705

main71955-48010-C0iMHU28200503-200705

main71956-48010-C0iMHU28200503-200705

71940AHEADREST ASSY, REAR SEAT

main71940-48210-C0×2iMHU28200503-200705

BLACK,TRIM2#

71960BHEADREST ASSY, REAR SEAT, CENTER

main71960-48250-C0iMHU28200503-200705

BLACK,TRIM2#

72057LEVER SUB-ASSY, REAR SEAT LOCK CONTROL, RH

main72058-48010-C0iMHU28200503-200705

BLACK,TRIM2#

72137CCOVER, SEAT TRACK INNER, RH

main72137-48070-C0iMHU28200503-200705

BLACK,TRIM2#

72137DCOVER, REAR SEAT TRACK, RH

main72137-48060-C0iMHU28200503-200705

BLACK,TRIM2#

72152ACOVER, REAR SEAT TRACK BRACKET, INNER

main72152-48040-C0iMHU28200503-200705

main72159-48100-C0iMHU28200503-200705

72157BCOVER, REAR SEAT TRACK BRACKET, INNER RH

main72157-48060-C0iMHU28200503-200705

BLACK,TRIM2#

72159BCOVER, REAR SEAT TRACK BRACKET, OUTER

main72152-48040-C0iMHU28200503-200705

main72159-48100-C0iMHU28200503-200705

72160TRACK ASSY, REAR SEAT, OUTER RH

main72160-48070iMHU28200503

72173HANDLE, REAR SEAT TRACK ADJUSTING

main72173-48040×2iMHU28200503

72180CTRACK ASSY, REAR SEAT, INNER RH

main72180-48070iMHU28200503

72265ACOVER, SEAT TRACK UPPER RAIL, RH

main72265-48010-C0iMHU28200503-200705

BLACK,TRIM2#

72307LINK SUB-ASSY, RECLINING CONTROL, RH

main72307-48080iMHU28200503

72497ECOVER, VERTICAL ADJUSTER BRACKET, OUTER

main72497-48010-C0iMHU28200503-200705

BLACK,TRIM2#

72551ECOVER, RECLINING HINGE, RH

main72551-48020-C0iMHU28200503-200705

BLACK,TRIM2#

72553CPROTECTOR, RECLINING COVER, RH

main72553-48060-C0iMHU28200503-200705

BLACK,TRIM2#

72554APROTECTOR, RECLINING COVER, LH

main72554-48060-C0iMHU28200503-200705

BLACK,TRIM2#

72615ACOVER, REAR SEATBACK LOCK STRIKER, RH

main72615-48020-C0iMHU28200503-200705

BLACK,TRIM2#

72667BEZEL, REAR SEATBACK LOCK, UPPER

main72667-48010-C0iMHU28200503-200705

BLACK,TRIM2#

72704ACABLE, REAR SEAT RECLINING CONTROL

main72704-48040iMHU28200503

72749SPACER, REAR SEAT RECLINING

main72749-48010×4iMHU28200503-200705

main72749-48020×4iMHU28200503-200705

72749ASPACER, REAR SEAT RECLINING

main72749-48030×2iMHU28200503

72978COVER, NO.2 CENTER SEATBACK

main72978-48020-C0iMHU28200503-200705

BLACK,TRIM2#

72996COVER, REAR SEATBACK, RH

main72996-48030-C0×2iMHU28200503-200705

BLACK,TRIM2#

72996BCOVER, REAR SEATBACK, INNER RH

main72996-48040-C0iMHU28200503-200705

BLACK,TRIM2#

79011COVER SUB-ASSY, NO.1 SEAT CUSHION, RH

main79011-48010-C0iMHU28200503-200705

main79011-48020-C0iMHU28200503-200705

79081CCOVER, REAR SEAT, NO.1

main79081-48040iMHU28200503

79081ECOVER, REAR SEAT, NO.3

main79081-48060iMHU28200503

79157COVER, NO.1 SEATBACK

main79157-48020-C0iMHU28200503-200705

BLACK,TRIM2#

79801CFRAME, FOLD SEAT CUSHION, NO.2

main79801-48030iMHU28200503

main79801-48040iMHU28200503

7270244070BRACKET SUB-ASSY, REAR SEATBACK STRIKER

main72702-44070

7889948010BOLT, FRONT SEAT

main78899-48010

7889948020BOLT, FRONT SEAT

main78899-48020

7889948030BOLT, FRONT SEAT

main78899-48030

7889948040BOLT, FRONT SEAT

main78899-48040

7889948050BOLT, FRONT SEAT

main78899-48050

9010508253

main90105-08253

9010510523

main90105-10523

9011908134

main90119-08134

9016740044

main90167-40044

9020112014

main90201-12014

9321955016

main93219-55016

9352053008

main93520-53008

9356054014

main93560-54014

9415081000

main94150-81000

65 parts on this diagram · 4 diagrams in section
