SEAT BELT & CHILD RESTRAINT SEAT

0001 1 0002 1

73165INSERT, FRONT SHOULDER BELT HANGER, RH

main73165-77010iLFA10201012-201212

73165AINSERT, FRONT SHOULDER BELT HANGER, LH

main73165-77010iLFA10201012-201212

73172BCAP, FRONT SHOULDER BELT HANGER, RH

main73172-77010-B0iLFA10201012-201212

main73172-77010-C0iLFA10201012-201212

73173DCAP, FRONT SHOULDER BELT HANGER, LH

main73173-77010-B0iLFA10201012-201212

main73173-77010-C0iLFA10201012-201212

73176HANGER, FRONT SHOULDER BELT, RH (FOR FRONT SEAT)

main73176-77010supersedes 73176-77020iLFA10201012-201212

73177HANGER, FRONT SHOULDER BELT, LH (FOR FRONT SEAT)

main73177-77010supersedes 73177-77020iLFA10201012-201212

73210BELT ASSY, FRONT SEAT OUTER, RH

main73210-77010-C2iLFA10201012-201111

BLACK/BROWNISH BLACK,TRIM20

main73210-77010-C3iLFA10201012-201111

BLACK/SATIN SILVER,TRIM20

main73210-77011-C2iLFA10201111-201212

BLACK/BROWNISH BLACK,TRIM20

main73210-77011-C3iLFA10201111-201212

BLACK/SATIN SILVER,TRIM20

73220BELT ASSY, FRONT SEAT OUTER, LH

main73220-77010-C2iLFA10201012-201111

BLACK/BROWNISH BLACK,TRIM20

main73220-77010-C3iLFA10201012-201111

BLACK/STAIN SILVER,TRIM20

main73220-77011-C2iLFA10201111-201212

BLACK/BROWNISH BLACK,TRIM20

main73220-77011-C3iLFA10201111-201212

BLACK/SATIN SILVER,TRIM20

73230BELT ASSY, FRONT SEAT INNER, RH

main73230-77030-C0iLFA10201012-201212

TRIM2#

73233COVER, LAP BELT OUTER ANCHOR

main73233-77010-C0×2iLFA10201012-201212

BLACK,TRIM2#

73240BELT ASSY, FRONT SEAT INNER, LH

main73240-77020-C0iLFA10201012-201212

TRIM2#

73250ARETRACTOR ASSY, FRONT SEAT BELT, RH

main73250-77020-C0iLFA10201012-201212

main73250-77020-C2iLFA10201012-201212

73260RETRACTOR ASSY, FRONT SEAT BELT, LH

main73260-77010-C0iLFA10201012-201212

main73260-77010-C2iLFA10201012-201212

78899BBOLT, FRONT SEAT

main78899-77020×4iLFA10201012-201212

7321977010STOPPER, TONGUE PLATE

main73219-77010

9017911010

main90179-11010

9155180825

main91551-80825

17 parts on this diagram · 2 diagrams in section
