DISC WHEEL & WHEEL CAP

0001 1 0002 1

42601BBOLT, HUB (FOR AXLE)

main90942-02084×20iLFA10201012

42601FWHEEL, DISC (FOR FRONT)

main42611-77020×2supersedes 4261A-77010iLFA10201012-201212

main4261A-77020×2supersedes 4261A-77010iLFA10201012-201212

main4261A-77050×2supersedes 4261A-77010iLFA10201201-201212

42601RWHEEL, DISC (FOR REAR)

main42611-77040×2supersedes 4261A-77030iLFA10201012-201212

main4261A-77040×2supersedes 4261A-77030iLFA10201012-201212

main4261A-77060×2supersedes 4261A-77030iLFA10201201-201212

42603ORNAMENT SUB-ASSY, WHEEL HUB

main42603-53110×4iLFA10201012

42611GVALVE (FOR TUBELESS TIRE)

main90942-05028×4iLFA10201012-201212

42611UCAP, TIRE VALVE

main90942-05029×4iLFA10201012-201212

6 parts on this diagram · 2 diagrams in section
