FRONT AXLE ARM & STEERING KNUCKLE

Parts diagram
43211KNUCKLE, STEERING, RH
main43211-33060i199704-200112
main43211-33070i199706-200112
43211KBOLT (FOR STEERING KNUCKLE RH)
main90105-17001×2i199704-200107
main90105-17003i199704-200107
main90105-17004i199704-200107
main90105-17005i199704-200107
main90105-17008×2i200107-200112
main90105-17009i200107-200112
main90105-17010i200107-200112
main90105-17011i200107-200112
43211LNUT (FOR STEERING KNUCKLE RH)
main90178-17001×2i200107-200112
main90179-17001×2i199704-200107
43212KNUCKLE, STEERING, LH
main43212-33060i199704-200112
main43212-33070i199706-200112
43212DBOLT (FOR STEERING KNUCKLE LH)
main90105-17001×2i199704-200107
main90105-17003i199704-200107
main90105-17004i199704-200107
main90105-17005i199704-200107
main90105-17008×2i200107-200112
main90105-17009i200107-200112
main90105-17010i200107-200112
main90105-17011i200107-200112
43212ENUT (FOR STEERING KNUCKLE LH)
main90178-17001×2i200107-200112
main90179-17001×2i199704-200107
43330KJOINT ASSY, LOWER BALL, FRONT RH
main43330-39435i199704-200112
43330LNUT, CASTLE (FOR FRONT LOWER BALL JOINT RH)
main90171-14003i199704-200112
43340AJOINT ASSY, LOWER BALL, FRONT LH
main43330-39435i199704-200112
43340BNUT, CASTLE (FOR FRONT LOWER BALL JOINT LH)
main90171-14003i199704-200112
48068ARM SUB-ASSY, FRONT SUSPENSION, LOWER NO.1 RH
main48068-33030i199704-200112
sub48068-33031
48069ARM SUB-ASSY, FRONT SUSPENSION, LOWER NO.1 LH
main48069-33030i199704-200112
sub48069-33031
48657ASTOPPER, FRONT LOWER ARM BUSH
main48657-33020×2i199704-200112
9010512216
main90105-12216
9010514081
main90105-14081
9010514084
main90105-14084
9017912103
main90179-12103
9017914048
main90179-14048
9538103225
main95381-03225

19 parts on this diagram · 1 diagram in section
