THROTTLE LINK & VALVE LEVER (ATM)

0001 1A541E,A541F 0003 1A140E 0004 1A541E,A541F 0006 1A140E 0007 1U140E

35501ROD SUB-ASSY, PARKING LOCK

main35501-21010iMCV20199908-200112

main35501-32030iSXV20199704-200112

main35501-33010iMCV2#,SXV25199704-199908

35505LEVER SUB-ASSY, MANUAL VALVE

main35505-21010iMCV20199908-200112

main35505-32040iMCV2#,SXV2#199704-199908

35505BSPACER (FOR MANUAL VALVE LEVER)

main90560-20006iMCV2#,SXV2#199704-200112

35505GPIN, SLOTTED SPRING (FOR MANUAL VALVE LEVER)

main90254-04011iMCV2#,SXV2#199704-200112

35506FSEAL, OIL (FOR MANUAL VALVE LEVER SHAFT)

main90311-12002iMCV2#,SXV2#199704-200112

35506JSPRING, RETAINER (FOR MANUAL VALVE LEVER SHAFT)

main90524-09001iMCV2#,SXV2#199704-200112

35556SHAFT, PARKING LOCK PAWL

main35556-21010iMCV20199908-200112

main35556-32010iSXV20199704-200112

main35556-32020iMCV2#,SXV25199704-199908

35557PAWL, PARKING LOCK

main35557-32020iSXV20199704-200112

main35557-33010iMCV2#,SXV25199704-199908

main35590-21010iMCV20199908-200112

35557ASPRING, TORSION (FOR PARKING LOCK PAWL)

main90506-18077iMCV20199908-200112

main90508-26047iSXV20199704-200112

main90949-03043iMCV2#,SXV25199704-199908

35561SHAFT, MANUAL VALVE LEVER

main35561-21010iMCV20199908-200112

main35561-32010iSXV20199704-200112

main35561-33010iMCV2#,SXV25199704-199908

35572ALEVER, TRANSMISSION CONTROL SHAFT

main35572-33010iMCV2#,SXV2#199704-199908

main35572-48010iMCV20199908-200112

35593SLEEVE, CAM GUIDE

main35593-33010iMCV2#,SXV25199704-199908

35595BRACKET, PARKING LOCK PAWL

main35595-21010iMCV20199908-200112

main35595-32010iSXV20199704-200112

main35595-33010iMCV21,25,SXV25199908-200112

91611B0614

main91611-B0614

9411050800

main94110-50800

9451200800

main94512-00800

16 parts on this diagram · 5 diagrams in section
