CAUTION PLATE & NAME PLATE (ENGINE)

11289PLATE, SPARK PLUG CAUTION

main11289-20010i5SFE..SXV2#199704

main11289-46020i1MZFE,2MZFE..MCV2#199704-199908

11296ALABEL, ENGINE SERVICE INFORMATION

main11296-20030i1MZFE..MCV20199704-199908

main11296-20040i2MZFE..MCV21,25199704

main11296-20050i1MZFE..MCV20199908

main11296-74180i5SFE..SXV2#199704

16701GLABEL, CAUTION

main88723-20081i1MZFE,2MZFE,5SFE..MCV2#,SXV2#199704

17791LABEL, MAINTENANCE INFORMATION

main17791-74040i1MZFE,2MZFE,5SFE..MCV2#,SXV2#199704

1356410010LABEL, TIMING BELT REPLACEMENT INFORMATION

main13564-10010

5 parts on this diagram · 1 diagram in section
