21011CASE SUB-ASSY, AUTOMATIC CHOKE

main21011-51011i196711-197008

main21011-51012i197008-197010

main21011-51013i197010-197302

main21011-52010i197303-197407

main21011-52011i197407-197505

21025GAGE SUB-ASSY, CARBURETOR LEVEL

main21025-51010i196711-196810

main21025-51011i196810-197310

main21025-52010i197310-197505

21069DASH POT SUB-ASSY

main21069-31240i197603-197811

main21069-51010i196711-196801

main21069-51011i196801-197302

main21069-52010i197303-197603

21112HORN, AIR

main21012-52040i197505-197603

main21012-52041i197603-197701

main21112-51010i196711-196805

main21112-51011i196805-196806

main21112-51012i196806-196904

main21112-51014i196904-196908

main21112-51015i196908-197505

21113FLANGE, CARBURETOR

main21113-51010i196711-196808

main21113-51011i196808-196810

main21113-51013i196810-197010

main21113-51014i197010-197103

main21113-51015i197103-197108

main21113-51016i197108-197302

main21113-52010i197303-197407

21175CASE, HIGH SPEED VALVE

main21175-51010i196711-197811

21206STRAINER SUB-ASSY

main21294-51010×2i196711-197505

21209FLOAT SUB-ASSY

main21289-51010×2i196711-197811

21211VENTURI, 1ST SMALL

main21211-51013i196711-197002

main21211-51014i197002-197010

main21211-51015i197010-197302

main21211-52010i197407-197505

main21211-52020i197303-197405

21212VENTURI, 2ND SMALL

main21212-51011i196711-197002

main21212-51012i197002-197010

main21212-51013i197010-197505

21251JET, 1ST MAIN

main21251-41015×2i197010-197302

ID=0.99

main21251-51010×2i196711-196808

ID=0.96

main21251-51011×2i196808-196904

ID=0.96

main21251-51012×2i196904-197002

ID=0.96

main21251-51013×2i197002-197010

ID=0.98

main90999-41100×2i197407-197505

ID=1.00

main90999-41102×2i197303-197407

ID=1.02

main90999-41103×2i197505-197701

ID=1.03

main90999-41104×2i197701-197811

ID=1.04

21253JET, 2ND MAIN

main21253-44011×2i197002-197010

ID=1.45

main21253-51010×2i196711-196808

ID=1.35

main21253-51011×2i196808-196904

ID=1.35

main21253-51012×2i196904-197002

ID=1.35

main21253-51013×2i197010-197505

ID=1.40

main90999-42135×2i197505-197701

ID=1.35

main90999-42141×2i197701-197811

ID=1.41

21271SCREW, IDLE ADJUSTING

main21271-51012×2i196711-197103

main21271-51013×2i197103-197105

main21271-51014×2i197105-197505

main21271-52040×2i197505-197701

main21271-52041×2i197701-197811

21272SCREW, 1ST IDLE ADJUSTING

main21272-51010i196711-196810

main21272-51011i196810-197811

21273SCREW, THROTTLE ADJUSTING

main21273-51010i196811-197811

main21273-60012i196808-196811

21299NET, PUMP FILTER

main21299-51010i196711-197811

21301VALVE SUB-ASSY, NEEDLE

main21301-51010×2i196711-196810

main21301-51011×2i196810-196910

main21301-52040×2i197505-197811

21312BALL, STEEL

main21313-52010i197303-197811

21313BALL, STEEL, NO.1(FOR DISCHARGE WEIGHT)

main21313-11020i196711-197811

21331VALVE, 1ST THROTTLE

main21331-51010×2i196711-197505

21335VALVE, THERMOSTATIC

main21061-52041i197505-197603

main21061-52042i197603-197811

main21335-51010i196711-197505

21341VALVE, POWER

main21341-51010i196711-196805

main21341-51011i196805-196806

main21341-51012i196806-196904

main21341-51013i196904-197002

main21341-51014i197002-197010

main21341-51015i197010-197407

main21341-52010i197407-197701

21351PISTON, POWER

main21351-51010i196908-197002

main21351-51011i197002-197701

21353PLUNGER, PUMP

main21035-51011i196711-196810

main21035-51012i196810-197811

21371CAM, 1ST IDLE

main21371-51010i196711-197010

main21371-51011i197010-197302

main21371-52010i197303-197505

21399SUPPORT(FOR DASH POT)

main21399-51010i196711-196801

main21399-51011i196801-196806

main21399-51012i196806-197302

main21399-52011i197303-197505

21412SHAFT, 1ST THROTTLE

main21412-51010i196711-197505

21413SHAFT, 2ND THROTTLE

main21049-51010i196711-197302

main21049-51011i197303-197505

21414SHAFT, CHOKE

main21054-51010i196711-197010

main21054-51011i197010-197505

main21054-52040i197505-197811

21448LEVER, 1ST KICK

main21448-51010i196711-197505

21452LEVER, PUMP

main21452-51010i196711-197505

21453LEVER, 1ST THROTTLE

main21453-51010i196711-196806

main21453-51013i196806-196808

main21453-51014i196808-197302

main21453-52010i197303-197505

21461LEVER, 1ST IDLE

main21461-51011i197303-197505

21471LINK, PUMP CONNECTING

main21471-51010i196711-197302

main21471-51020i196711-197302

21473LINK, THROTTLE SHAFT

main21473-51010i196711-197010

main21473-51011i197010-197505

21474LINK, CONNECTING

main21474-51010i196711-197505

21477LINK, CHOKE LEVER

main21477-51010i196711-197302

main21477-51011i197303-197505

21531RETAINER, COIL HOUSING

main21531-30010×3i196711-197505

21557SPACER(FOR 1ST IDLE CAM)

main21557-51010i197010-197505

21561WEIGHT, PUMP DISCHARGE

main21561-25010i197303-197811

21572STOP, POWER PISTON

main21572-22010i196908-197010

main21572-60060i197010-197505

21579CAP, STRAINER

main21579-21030i196711-197811

21581SHIM, 1ST THROTTLE SHAFT

main21581-25010i197407-197505

T=0.1

main21582-25010i197407-197505

T=0.2

main21583-25010i197407-197505

T=0.3

21593PLATE(FOR THROTTLE RETURN SPRING SET)

main21593-51010×2i196711-197505

main21593-52040i197701-197811

21595RETAINER, SPRING

main21595-51010×4i196711-197811

21611GASKET, MAIN JET

main21611-22010×4i196711-197811

21614GASKET, VENTURI

main21614-51010×2i196711-197811

21617GASKET, MAIN PASSAGE PLUG

main21617-30010×4i196904-197505

21618GASKET, NEEDLE VALVE SEAT

main21618-24030×2i197505-197811

main21618-60010×2i196711-197505

21622GASKET, AIR HORN

main21622-51010i196711-197010

main21622-51011i197010-197811

21623GASKET, BODY FLANGE

main21623-51010i196711-197505

main21623-52040i197505-197811

21626GASKET, CASE

main21626-51010i196711-197302

main21626-51011i197303-197505

21627GASKET, COIL HOUSING

main21627-34080i197505-197811

main21627-51010i196711-197505

21649GASKET(FOR PUMP DISCHARGE WEIGHT STOPPER)

main21649-45070i197505-197701

main21649-45071i197701-197811

main21649-51010i196711-197505

21695BOOT(FOR DASH POT)

main21699-41010i196711-197811

21699BOOT(FOR PUMP PLUNGER)

main21699-51010i196711-197811

21722SPRING, PUMP DAMPING

main21722-51010i196711-197505

21723SPRING, IDLE ADJUSTING

main21723-51010×2i196711-197811

21724SPRING, THROTTLE ADJUSTING

main21724-51011i196711-197811

21726SPRING, 1ST IDLE ADJUSTING

main21726-40010i196711-197811

21729SPRING, 1ST THROTTLE BACK

main21729-51010i196711-196904

main21729-51011i196904-197505

21734SPRING, POWER PISTON

main21734-51010i196908-197002

main21734-51011i197002-197010

main21734-51012i197010-197302

main21734-52010i197303-197407

main21734-52011i197407-197505

main21734-52040i197505-197701

21763PIN, FLOAT LEVER

main21763-51010×2i196711-197811

21781PLUG, MAIN PASSAGE(FOR CARBURETOR JET)

main21782-51010×4i196904-197811

21791RING, SNAP, NO.1(FOR CARBURETOR LINK)

main21791-60010×11i196711-197811

21822SCREW, 1ST THROTTLE VALVE SET

main21822-51010×4i196711-197505

21824SCREW, SET(FOR 1ST IDLE CAM FOLLOWER SET)

main21824-33010×2i196808-197505

main21824-40010×2i196711-196808

21828SCREW, 1ST IDLE SET

main21828-51010i196711-196810

main21828-51011i196810-197010

main21828-51012i197010-197505

21831SCREW, POWER PISTON STOP

main21842-33010i196908-197811

21837SCREW, COIL HOUSING SET

main21821-25010×3i197505-197811

main21838-60011×3i196711-196808

main21842-33010×3i196808-197505

21842SCREW, SET(FOR CARBURETOR LEVEL GAGE CLAMP SET)

main21842-33010×3i196711-197811

21863WIRE(FOR FLOAT)

main21863-51010×2i196711-197811

21865SPRING

main21865-51010×2i196711-197811

21889ELBOW

main21889-51010i196711-196903

main21889-51011i196903-197505

2179269210RING, SNAP, NO.2(FOR CARBURETOR LINK)

main21792-69210

9321016020

main93210-16020

9321914025

main93219-14025

9328018028

main93280-18028

9331915020

main93319-15020

9411040800

main94110-40800

9451100400

main94511-00400

9451100800

main94511-00800

9451200600

main94512-00600

9451200800

main94512-00800

9461110300

main94611-10300

9461110400

main94611-10400
