THROTTLE LINK & VALVE LEVER (ATM)

0001 1 0002 1 0004 1 0005 1 0006 1 0007 1 0008 1 0009 1 0010 1

35501ROD SUB-ASSY, PARKING LOCK

main35501-22020iGS130,131,LS13#..ATM..(DSL,EFI,HTWC,TDE,TWC)198709-199110

main35501-26020iGS130,MS130,YS130..ATM..(LPEFI,LPG,TWLPG)198709-199110

main35501-30010iGS130,131..SPC;JZS13#,MS135,137,UZS131198709-199110

35505LEVER SUB-ASSY, MANUAL VALVE

main35505-22040iGS130..ATM..TWLPG199104-199110

main35505-22050iGS130,131,LS13#,YS130..ATM..(DSL,HTWC,LPEFI,TDE,TWC,TWLPG)198908-199104

main35505-22060iGS130,131..SPC;JZS13#,MS13#,UZS131198908-199110

main35505-30020iMS135,137;GS130,131..SPC198709-198808

main35505-30021iMS135,137;GS130,131..SPC198808-198908

35506CPIN, SLOTTED SPRING (FOR MANUAL VALVE LEVER SHAFT)

main90254-04011iGS130,131,JZS13#,LS13#,MS13#,UZS131,YS130..ATM198709-199110

35506FSEAL, OIL (FOR MANUAL VALVE LEVER SHAFT)

main90311-11001×2iGS130,131,LS13#,MS130,YS130..ATM..(DSL,EFI,HTWC,LPG,TDE,TWC)198709-198908

main90311-11003×2iGS130,131,LS13#,YS130..ATM..(DSL,HTWC,LPEFI,TDE,TWC,TWLPG)199107-199110

main90311-12002×2iGS130,131..SPC;JZS13#,MS135,137,UZS131198709-199110

35506HSPACER (FOR MANUAL VALVE LEVER SHAFT)

main90560-20003iGS130,131,LS13#,MS130,YS130..ATM..(DSL,EFI,HTWC,LPEFI,LPG,TDE,TWC,TWLPG)198709-199110

main90560-20006iGS130,131..SPC;JZS13#,MS135,137,UZS131198709-199110

35556SHAFT, PARKING LOCK PAWL

main35556-26010iGS130,131,MS130,YS130..ATM..(HTWC,LPG)198709-198908

main35556-30020iGS130,131..SPC;JZS13#,MS135,137,UZS131198709-199110

35556ERING, E (FOR PARKING LOCK PAWL SHAFT)

main90523-08021iGS130,131,JZS13#,LS13#,MS13#,UZS131,YS130..ATM198709-199110

35557PAWL, PARKING LOCK

main35557-26010iGS130,MS130,YS130..ATM..(LPEFI,LPG,TWLPG)198709-199110

main35557-30020iGS130,131..SPC;JZS13#,MS135,137,UZS131198709-199110

main35557-35010iGS130,131,LS13#..ATM..(DSL,EFI,HTWC,TDE,TWC)198709-199110

35557ASPRING, TORSION (FOR PARKING LOCK PAWL)

main90508-21001iGS130,MS130,YS130..ATM..(LPEFI,LPG,TWLPG)198709-199110

main90508-21002iGS130,131..SPC;JZS13#,MS135,137,UZS131198709-199110

main90508-25001iGS130,131,LS13#..ATM..(DSL,EFI,HTWC,TDE,TWC)198709-199110

35561SHAFT, MANUAL VALVE LEVER

main35561-30070iGS130,131..SPC;JZS13#,MS135,137198709-199110

main35561-40010iGS130,131,LS13#,MS130,YS130..ATM..(DSL,EFI,HTWC,LPEFI,LPG,TDE,TWC,TWLPG)198709-199110

main35561-50010iUZS131198908-199110

35572LEVER, TRANSMISSION CONTROL SHAFT, RH

main35572-22040iGS130,131,LS13#,MS130,YS130..ATM..(DSL,EFI,HTWC,LPEFI,LPG,TDE,TWC,TWLPG)198709-199110

main35572-30060iGS130,131..SPC;JZS13#,MS135,137,UZS131198709-199110

35595BRACKET, PARKING LOCK PAWL

main35595-30010iGS130,131..SPC;JZS13#,MS135,137,UZS131198709-199110

main35595-40010iGS130,131,MS130,YS130..ATM..(HTWC,LPG)198709-198908

9010106416

main90101-06416

9411050800

main94110-50800

9451200800

main94512-00800

9454200600

main94542-00600

16 parts on this diagram · 9 diagrams in section
