EXTENSION HOUSING (MTM)

33103HOUSING SUB-ASSY, EXTENSION(MTM)

main33103-14051iGX81..5F..(AVT,GT)198808-199110

main33103-22091iGX81,LX80,SX80..5F..(AVT,GT,SXL,XG,XL)198808-199110

main33103-24010iGX81..5F..AVT199110-199208

main33103-24011iGX81..5F..AVT199208-199210

main33103-30191iLX80,SX80,YX80..5F..KYO198808-199110

main33103-30200iGX81,LX80,SX80,YX80..5F199110-199208

main33103-30201iGX81,LX80,SX80,YX80..5F199208-199210

33103ABUSH(FOR MANUAL TRANSMISSION EXTENSION HOUSING)

main90999-73105iGX81,LX80,SX80,YX80..5F198808-199210

33103RSEAL, OIL(FOR MANUAL TRANSMISSION EXTENSION HOUSING)

main90311-38032iGX81,LX80,SX80,YX80..5F199110-199210

main90311-38040iGX81,LX80,SX80,YX80..5F198808-199110

33124FPIPE, OIL RECEIVER, NO.1(FOR EXTENSION HOUSING)

main33106-22010iGX81,LX80,SX80,YX80..5F198808-199110

main33106-30040iGX81,LX80,SX80,YX80..5F199110-199210

33146DEFLECTOR, EXTENSION HOUSING DUST(MTM)

main33146-30010iGX81,LX80,SX80,YX80..5F198808-199210

33148SHROUD, GEAR, NO.1

main33148-22010iGX81,LX80,SX80,YX80..5F198808-199110

33283HPLUG, W/HEAD STRAIGHT SCREW

main90341-10065×2iGX81,LX80,SX80,YX80..5F198808-199008

9011910019

main90119-10019

8 parts on this diagram · 1 diagram in section
