DISC WHEEL & WHEEL CAP

0001 1 0002 1 0003 1

42601WHEEL, DISC

main42611-75080×4supersedes 42611-75120iANF10200907-201301

main4261A-75030×4supersedes 42611-75120iANF10201301

42601AWHEEL, DISC (FOR SPARE)

main42611-12B30iANF10200907-201301

main42611-75100iANF10201406-201508

42601CNUT, HUB (FOR AXLE)

main90942-01033×20iANF10201301

42611GVALVE (FOR TUBELESS TIRE)

main90942-05028×4iANF10201301

42611JVALVE (FOR TUBELESS TIRE SPARE)

main90942-05009iANF10200907-201301

5 parts on this diagram · 3 diagrams in section
